IC687BEM713 总线扩展模块 双背板冗余机架中

【产品详情】

IC687BEM713模块是GE Fanuc Rx7i系列总线扩展模块。更具体地说，IC687BEM713模块是一个总线发送器模块，该总线发送器模块是GE Fanuc FIP冗余系统中必不可少的组件。一个完整的GE FIP冗余系统包含2个总线变送器模块，如IC687BEM713总线变送器模块。这些模块安装在系统的双背板冗余机架中。IC687BEM713总线变送器模块只需要 1 个 VME 插槽即可安装。此外，使用软件可以很容易地将该模块配置到PLC系统中，并且不需要设置任何DIP开关。该模块还支持并行编程器接口，这是一个高性能接口。它需要来自 5 伏总线的 1.4 安培电流才能运行。

GE Fanuc IC687BEM713 Rx7i 系列总线变送器模块旨在连接到 RCM 或冗余通信模块，以支持 FIP 冗余系统中的冗余通信。IC687BEM713模块安装在 2 节冗余机架的 1 个半部分，而冗余通信模块安装在另一半。请注意，这个 2 节冗余机架的每一半都需要有自己的总线发射器模块和自己的冗余通信模块。IC687BEM713总线变送器模块带有 2 个内置连接器。它使用顶部连接器连接到编程设备，并使用底部连接器连接到冗余通信模块。它有一个机械钥匙，可确保它安装在系统中的正确插槽中，并防止其他模块安装在其指定的插槽中。

IC687BEM713 总线扩展模块 双背板冗余机架中

【英文介绍】

The IC687BEM713 module is a GE Fanuc Rx7i series bus expansion module. More specifically, the IC687BEM713 module is a bus transmitter module, which is an essential component in a redundant GE Fanuc FIP system. A complete GE FIP redundant system consists of two bus transmitter modules, such as the IC687BEM713 bus transmitter module. These modules are installed in the system's dual backplane redundant rack. The IC687BEM713 bus transmitter module requires only 1 VME slot to install. In addition, the module can be easily configured into a PLC system using software, and no DIP switches need to be set up. The module also supports the parallel programmer interface, which is a high-performance interface. It requires 1.4 amps of current from a 5-volt bus to operate.

GE Fanuc IC687BEM713 Rx7i Series bus transmitter modules are designed to connect to RCM or redundant communication modules to support redundant communication in FIP redundant systems. The IC687BEM713 module is installed in one half of the 2 redundant racks, while the redundant communication module is installed in the other half. Note that each half of this 2-section redundant rack needs to have its own bus transmitter module and its own redundant communication module. The IC687BEM713 bus transmitter module comes with 2 built-in connectors. It is connected to the programming device using the top connector and to the redundant communication module using the bottom connector. It has a mechanical key that ensures it is installed in the correct slot in the system and prevents other modules from being installed in their designated slot.
