ADV559 配套接线组热电偶输入单元

☆型号：ADV559 配套接线组热电偶输入单元

【产品详情】

YOKOGAWA ADV559控制单元 配套接线组热电偶输入单元用于连接热电偶探头，将探头输出的温度信号转换为可由控制单元识别的数字信号。该接线组采用 2 线制连接方式，具有防水、防尘、耐腐蚀等特点。

接线组的主要组件如下：

连接器：用于连接热电偶探头

电路板：用于转换温度信号

接地端子：用于接地

接线组的使用方法如下：

将连接器连接到热电偶探头。

将电路板连接到控制单元。

将接地端子连接到接地点。

接线组的参数如下：

输入电压：24 VDC

输入电流：10 mA

输出信号：4-20 mA

温度范围：-200~+600 ℃

☆型号：ADV559 配套接线组热电偶输入单元

【英文介绍】

The YOKOGAWA ADV559 control unit is used to connect the thermocouple input unit to the thermocouple probe and convert the temperature signal output from the probe into a digital signal that can be recognized by the control unit. The wiring group adopts 2-wire connection mode and has the characteristics of waterproof, dustproof and corrosion resistance.

The main components of the wiring group are as follows:

Connector: Used to connect thermocouple probes

Circuit board: Used to convert temperature signals

Ground terminal: Used for grounding

The wiring group is used as follows:

Connect the connector to the thermocouple probe.

Connect the circuit board to the control unit.

Connect the ground terminal to the ground point.

The parameters of the wiring group are as follows:

Input voltage: 24 VDC

Input current: 10 mA

Output signal: 4-20 mA

Temperature range: -200~+600 ℃
