☆型号：XVME-560 32声道模拟输入模块 执行 12 位分辨率的 A/D 转换
【产品详情】
XVME-560型是由Xycom公司生产销售的VMEbus用32声道模拟输入模块。2023年12月，被视为停止销售。
概要
XVME-560型配备12位A/D转换器，可处理32个声道的模拟输入。具有最大50khz的转换速度和12位的分辨率，可以进行高精度的数据收集。
主要功能
32个声道的模拟输入
12位A/D转换器
最大50khz的转换速度
12位的分辨率
±5v的输入范围
利用软件进行增益调整
偏移调节功能
DMA传输
数字I/O
可选:
20khz、50khz的转换速度
14位、16位的分辨率
±2.5V的输入范围
特征：
跳线可选电压输入范围为 ±10 V、±2.5 V、0-10V、±5V、0-5V
可编程增益：1、2、4 或 8
可以在任何 VMEbus 级别中断 （11-17） （STAT）
20 KHz 转换速率
XVME-560 模拟输入模块是一个 VMEbus 背板兼容模块，可以在多达 64 个不同的单端输入通道或 32 个差分输入通道上执行 12 位分辨率的 A/D 转换。它由两部分组成：一个是包含执行模数转换所需的电路的模拟部分，另一个是将模拟电路连接到VMEbus的Xycom非智能内核部分。
