Vibro-meter VM600 RLC16 机械保护系统性能监测系统

【产品详情】

主要特性和优点

•来自振动计®产品线

•带有螺钉端子连接器的继电器卡

•16个继电器转换触点

•继电器驱动逆变逻辑(跳线可选)

•低接触电阻

•低电容

•高通功率

•实时插拔卡(热插拔)

•符合EMC的EC标准

描述

RLC16继电器卡设计用于VM600系列机械保护系统以及状态和性能监测系统，从美吉特的振动计®产品线。它是一张可选卡，供四时使用IOC4T输入/输出卡上的继电器是不足为申请和附加继电器是必需的。

RLC16安装在VM600机架后部(ABE04x或ABE056)，并直接连接到机架背板通过单连接器。RLC16包含16个具有转换功能的继电器联系人。每个继电器与3个端子相关联在可访问的螺旋端子连接器上

VM600机架后方。继电器由开路集电极驱动器控制在软件控制下。RLC16的跳线员卡允许继电器正常选择通电(NE)或正常断电(NDE)。有关使用RLC16卡的进一步资料一般情况下，参考VM600机械保护系统(MPS)硬件手册和

VM600 MPSx软件手册。具体应用请与当地联系Meggitt代表

Vibro-meter VM600 RLC16 机械保护系统性能监测系统

【英文介绍】

Key features and benefits

• From the Vibrometer ® product line

• Relay card with screw terminal connector

•16 relay transfer contacts

• Relay drive inverter logic (jumper optional)

• Low contact resistance

• Low capacitance

• High-pass power

• Real-time pluggable card (hot pluggable)

• Comply with EMC EC standards

Description

The RLC16 relay card is designed for use with VM600 series mechanical protection systems as well as condition and performance monitoring systems from Megite's Vibrometer ® product line. It is an optional card for 4-time use IOC4T input/output card on which the relay is insufficient for application and additional relays are required.

The RLC16 is mounted at the rear of the VM600 rack (ABE04x or ABE056) and is directly connected to the rack backplane via a single connector. The RLC16 contains 16 relay contacts with conversion capabilities. Each relay is associated with 3 terminals in an accessible spiral terminal connector

The rear of the VM600 rack. The relay is controlled by an open collector driver under software control. The RLC16's jumper card allows the relay to choose between normal power on (NE) or normal power off (NDE). For further information on using the RLC16 card in general, refer to the VM600 Mechanical Protection System (MPS) Hardware Manual and

VM600 MPSx Software Manual. For specific applications, please contact your local Meggitt representative
