140CRA31200C RIO DROP E/IP 1通道 具有多个本地信令通道

【产品详情】

特征

140CRA31200 具有多个本地信令通道。1 个绿色 LED 用于 RUN，1 个绿色/红色 LED 用于模块状态，1 个绿色/红色 LED 用于网络通信状态，1 个红色 LED 用于 I/O。此适配器模块占用 in Quantum 遥控器的主（第一个）机架中的一个插槽。昆腾远程 I/O 分支中的扩展（第二个）机架不需要适配器。

如何使用 140CRA31200

要设置以太网远程 I/O 断开在网络上的位置，请在为模块通电和下载应用程序之前使用 140CRA31200 前面的旋转开关。设置的值在电源循环期间应用。如果在模块通电后更改了开关设置，则会激活 Mod 状态 LED，并在模块的诊断系统中记录不匹配消息。

优势

由于旋转开关上的新值是在下一个电源循环时实现的，因此建议您在启动模块之前设置这些值。有效值介于 00 到 159 之间。这些旋转开关可以在 140CRA31200 上使用小平头螺丝刀进行操作，无需软件即可配置或启用旋转开关。请勿使用 Ones 旋转开关上的 Stored 和 Clear IP 设置，请记住，这些设置的功能不适用于远程 I/O 安装。

140CRA31200C RIO DROP E/IP 1通道 具有多个本地信令通道

【英文介绍】

trait

140CRA31200 has multiple local signaling channels. 1 green LED for RUN, 1 green/red LED for module status, 1 green/red LED for network communication status, and 1 red LED for I/O. This adapter module occupies a slot in the main (first) rack of the remote control in Quantum. The extension (second) rack in the Quinten remote I/O branch does not require an adapter.

How to use 140CRA31200

To set the location of the Ethernet remote I/O disconnect on the network, use the rotary switch in front of the 140CRA31200 before powering the module and downloading the application. The value set is applied during the power cycle. If the switch Settings are changed after the module is powered on, the Mod status LED is activated and a mismatch message is recorded in the module's diagnostic system.

advantage

Since the new values on the rotary switch are implemented on the next power cycle, it is recommended that you set these values before starting the module. Valid values range from 00 to 159. These rotary switches can be operated on the 140CRA31200 using a small flat head screwdriver and can be configured or enabled without software. Do not use the Stored and Clear IP Settings on the Ones rotary switch, remember that the functionality of these Settings does not apply to remote I/O installations.
