SCHNEIDER 140CPU65260 奔腾Unity处理器 通信端口

【产品详情】

产品系列  Modicon Quantum 自动化平台

产品类型  Unity处理器

Modicon Quantum 140CPU65260是一款奔腾Unity处理器，具有3072 kB的内部RAM和266 MHz的时钟频率。它有 2 个本地机架，可以有 6 个可选模块：以太网、Modbus、Modbus Plus、Profibus DP 和 Sy/Max。该模块有 2 个本地信令 LED – 1 个红色表示以太网冲突，1 个绿色表示以太网活动。这些产品在法国制造，专为物料搬运、包装和纺织机械使用而设计。它们提供MRO电气的2年保修。我们还提供来自其他制造商的CPU，如Modicon和ABB。

特征

140CPU65260共有4个通信端口。一个Modbus （RS-232 / RS-485），一个Modbus Plus（RS-485），一个USB和一个以太网。CPU模块需要2760 mA的总线电流。该模块还带有一个按键开关。其离散（位）参考容量为62 kBytes，寄存器（字）参考容量也为64 kBytes。它的电池保质期为10年，使用寿命为12 mAh。140CPU65260使用3V锂电池。

CPU 模块包含许多内置诊断功能。通电时，它将检查并诊断 RAM、RAM 地址、执行校验和、用户逻辑和处理器的任何问题。运行时，它将检查除处理器之外的所有这些功能。

优势

140CPU65260固件历史悠久。启动版本是Unity Pro V2.0。随着时间的推移，对各种固件版本进行了 50+ 次更改，纠正了许多错误和问题。您应始终将模块更新到最新的固件版本。大于 V3.30 的固件版本必须与 Copro 版本 5.8 一起使用。

如何使用 140CPU65260

140CPU65260 固件版本 V3.5 和所有以前的版本都包含硬编码的后门程序，这些后门程序会产生多个漏洞，允许黑客（甚至是远程漏洞）查看固件、修改模块的网站、修改密码以及下载和运行自定义固件。

SCHNEIDER 140CPU65260 奔腾Unity处理器 通信端口

【英文介绍】

Product family Modicon Quantum automation platform

Product Type Unity Processor

The Modicon Quantum 140CPU65260 is a Pentium Unity processor with 3072 kB of internal RAM and a clock rate of 266 MHz. It has 2 local racks and can have 6 optional modules: Ethernet, Modbus, Modbus Plus, Profibus DP and Sy/Max. The module has 2 local signaling leds - 1 red for Ethernet conflicts and 1 green for Ethernet activity. Manufactured in France, these products are designed for material handling, packaging and textile machinery use. They come with a 2-year warranty on MRO Electric. We also offer cpus from other manufacturers such as Modicon and ABB.

trait

140CPU65260 A total of four communication ports. One Modbus (RS-232 / RS-485), one Modbus Plus (RS-485), one USB and one Ethernet. The CPU module requires 2760 mA of bus current. The module also has a key switch. It has a discrete (bit) reference capacity of 62 kBytes and a register (word) reference capacity of 64 kBytes. It has a battery life of 10 years and a service life of 12 mAh. 140CPU65260 Uses a 3V lithium battery.

The CPU module contains many built-in diagnostic functions. When powered on, it checks and diagnoses any problems with RAM, RAM addresses, execution checksums, user logic, and the processor. At runtime, it checks all of these functions except for the processor.

advantage

The 140CPU65260 firmware has a long history. The startup version is Unity Pro V2.0. Over time, 50+ changes were made to various firmware versions, correcting many errors and issues. You should always update your modules to the latest firmware version. Firmware versions greater than V3.30 must be used with Copro version 5.8.

How to use 140CPU65260

140CPU65260 firmware version V3.5 and all previous versions contain hard-coded backdoors that create multiple vulnerabilities that allow hackers, even remotely, to view the firmware, modify the module's website, change passwords, and download and run custom firmware.
