140ATI03000 模拟输入模块 - 8 I 热电偶
【产品详情】
140ATI03000模块采用标准格式构建,使其与各种系统和设置兼容。它配备了一个单极点低通滤波器,在3 Hz时提供20 dB截止,以及一个在3/50 Hz时提供60 dB截止的陷波滤波器。这些滤波器有助于消除输入信号中不必要的噪声和干扰,确保准确可靠的数据采集。
输入
该模块具有八个模拟输入通道,可灵活地测量和监控各种热电偶输入。它支持不同的热电偶类型及其相应的温度范围。这些包括热电偶S(-50至1665°C),热电偶R(-50至1665°C),热电偶T(-270至400°C),热电偶K(-270至1370°C),热电偶E(-270至1000°C)和热电偶J(-210至760°C)。这种宽温度范围能力允许该模块在各种工业环境中应用。
该模块提供分辨率为 16 位的高分辨率模拟输入,确保精确的测量和控制。它的输入阻抗大于 1 MOhm,可在不影响测量数据完整性的情况下实现准确的信号捕获。
性能
在精度方面,140ATI03000模块表现出令人印象深刻的性能。它具有绝对精度误差,该误差因所使用的热电偶类型而异。对于热电偶S和R,误差在+/- 4°C加上读数的0.1%以内。对于热电偶T,K,J和E,误差在+/- 2°C加上读数的0.1%以内。该模块还具有出色的线性度,误差为 1 °C 或 0.1 °C(取决于温度范围)。
特征
温度变化会影响测量精度,但 140ATI03000 模块通过其精度漂移功能对此进行了补偿。它的最大低电平电压漂移为 0.15 μV/°C 加上读数/°C 的 0.0015%,从而最大限度地减少了温度变化对测量精度的影响。
该模块提供强大的共模抑制,在 120/50 Hz 时超过 60 dB。这种高抑制电平有助于消除共模噪声和干扰,确保信号干净准确。
安全
安全性是工业应用的一个重要方面,140ATI03000模块集成了全面的隔离功能。它在通道和总线之间提供隔离,耐受电压为 2500 V DC,持续 60 秒,1780 V AC 持续 60 秒。此外,它还在 220 V AC 和 300 V DC 额定值的通道之间提供隔离,从而增强安全性并防止潜在的电气危险。
通信
该模块具有通过 LED 发出本地信号的功能,其中 8 个红色 LED 指示通道故障,8 个绿色 LED 指示相应通道已打开。此外,还有两个 LED:一个红色 LED 指示外部故障,一个绿色 LED 指示活动总线通信。
该模块的总线电流要求为280 mA,功耗为1.5 W,可在最大限度降低功耗的同时高效运行。
施耐德电气部件号 140ATI03000 标有 CE 认证,表明符合欧洲安全标准。
总之,施耐德电气的140ATI03000 I/O模块是一款专为工业应用而设计的多功能可靠设备。凭借其多个模拟输入通道、热电偶兼容性、高分辨率、精度和强大的隔离功能,该模块可提供准确和精确的数据采集功能。其标准格式、全面的滤波和本地信令使其成为各种工业自动化系统中的重要组件。
140ATI03000 模拟输入模块 - 8 I 热电偶
【英文介绍】
The 140ATI03000 module is built in a standard format, making it compatible with a variety of systems and Settings. It is equipped with a unipolar point low-pass filter that provides a 20 dB cutoff at 3 Hz, and a notch filter that provides a 60 dB cutoff at 3/50 Hz. These filters help eliminate unnecessary noise and interference in the input signal, ensuring accurate and reliable data acquisition.
input
The module has eight analog input channels to flexibly measure and monitor a variety of thermocouple inputs. It supports different thermocouple types and their corresponding temperature ranges. These include thermocouple S (-50 to 1665°C), thermocouple R (-50 to 1665°C), thermocouple T (-270 to 400°C), thermocouple K (-270 to 1370°C), thermocouple E (-270 to 1000°C), and thermocouple J (-210 to 760°C). This wide temperature range capability allows the module to be used in a variety of industrial environments.
The module provides high-resolution analog inputs with a resolution of 16 bits, ensuring accurate measurement and control. Its input impedance is greater than 1 MOhm, enabling accurate signal capture without compromising the integrity of the measured data.
property
In terms of accuracy, the 140ATI03000 module shows impressive performance. It has an absolute accuracy error, which varies depending on the type of thermocouple used. For thermocouples S and R, the error is within 0.1% of +/ -4 °C plus the reading. For thermocouples T, K, J and E, the error is within 0.1% of +/ -2 °C plus the reading. The module also has excellent linearity, with an error of 1 °C or 0.1 °C (depending on the temperature range).
trait
Temperature changes can affect measurement accuracy, but the 140ATI03000 module compensates for this with its accuracy drift function. It has a maximum low-level voltage drift of 0.15 μV/°C plus 0.0015% of the reading /°C, thus minimizing the impact of temperature changes on measurement accuracy.
The module provides strong common-mode rejection, exceeding 60 dB at 120/50 Hz. This high rejection level helps eliminate common mode noise and interference, ensuring a clean and accurate signal.
secure
Security is an important aspect of industrial applications, and the 140ATI03000 module integrates comprehensive isolation capabilities. It provides isolation between the channel and the bus with a withstand voltage of 2500 V DC for 60 seconds and 1780 V AC for 60 seconds. In addition, it provides isolation between 220 V AC and 300 V DC rated channels, thus enhancing safety and preventing potential electrical hazards.
communication
The module has the function of sending out local signals through leds, in which eight red leds indicate that the channel is faulty and eight green leds indicate that the corresponding channel is open. In addition, there are two leds: a red LED indicating an external fault and a green LED indicating active bus communication.
The module requires a bus current of 280 mA and a power consumption of 1.5 W, allowing efficient operation while minimizing power consumption.
The Schneider Electric part number 140ATI03000 is CE certified, indicating compliance with European safety standards.
In short, the 140ATI03000 I/O module from Schneider Electric is a versatile and reliable device designed for industrial applications. With its multiple analog input channels, thermocouple compatibility, high resolution, precision and powerful isolation, the module provides accurate and precise data acquisition capabilities. Its standard format, comprehensive filtering and local signaling make it an important component in various industrial automation systems.
