140DDO84300 直流离散输出模块 提供 16 个离散输出通道

【产品详情】

施耐德电气部件号 140DDO84300 是一款专为工业自动化应用而设计的高质量直流离散输出模块。该模块由业内值得信赖的施耐德电气制造，可提供可靠的性能和强大的功能。这些产品在法国制造，专为物料搬运、包装和纺织机械使用而设计。它们提供MRO电气的2年保修。我们还提供来自其他制造商的I / O模块，如Modicon和ABB。

设计

140DDO84300 模块属于 I/O 模块类别，是标准格式模块。它专门设计为直流离散输出模块，提供 16 个离散输出通道，用于控制外部设备或过程。这些输出分为两组，每组由八个通道组成。

操作

该模块在负逻辑（也称为灌电流逻辑）上工作，这意味着当逻辑信号低电平时，输出处于活动状态。它需要 1 个输出字进行寻址，使其易于集成到控制系统或网络中。

功能

该模块的离散输出电压范围为 10 至 60 V DC，输出电压限值为 10.2 至 72 V。该模块可承受 72 V 的最大永久输出电压，确保耐用性和电压尖峰保护。在1 A负载电流下，其压降小于或等于2 V。

每个模块可以处理 12 A 的最大负载电流，而每组的负载电流限制为 6 A。在发生浪涌时，该模块可以处理高达 7.5 A 的浪涌电流，持续 50 秒。该模块的响应时间非常快，状态 1 和状态 0 之间以及状态 1 和状态 1 之间的转换时间小于或等于 0 ms。

特征

该模块通过每组 8 A 保险丝提供内部输出保护，确保所连接设备的安全性。每个分立输出点的相关保险丝额定值为2 A，而每组需要8 A保险丝。

安全

安全和隔离在工业应用中至关重要，该模块可提供足够的保护。它在通道和总线之间提供 2500 Vrms DC 隔离 1 分钟，并在 700 Vrms DC 下提供两组之间的隔离 1 分钟。这些隔离措施有助于提高安全性并防止通道和组之间的干扰。

合规

该模块标有CE认证，表明其符合欧洲安全标准。它还具有通过 LED 发出本地信号的功能，包括指示总线通信活动的绿色 LED、指示外部故障检测的红色 LED 和显示输入状态的 16 个绿色 LED。

在功率要求方面，该模块消耗160 mA的总线电流。功耗计算为1 W加1 V乘以模块总负载电流，确保高效的电源管理。

施耐德电气 2DDO140 模块享有 84300 年保修，可为各种工业自动化应用提供可靠的性能、灵活性和安全性。其坚固的结构、高速响应时间和全面的保护功能使其成为在工业环境中控制分立输出的绝佳选择。

140DDO84300 直流离散输出模块 提供 16 个离散输出通道

【英文介绍】

Schneider Electric Part Number 140DDO84300 is a high quality DC discrete output module designed for industrial automation applications. Manufactured by the industry's trusted Schneider Electric, the module delivers reliable performance and powerful features. Manufactured in France, these products are designed for material handling, packaging and textile machinery use. They come with a 2-year warranty on MRO Electric. We also offer I/O modules from other manufacturers such as Modicon and ABB.

design

The 140DDO84300 module belongs to the I/O module category and is a standard format module. Specifically designed as a DC discrete output module, it provides 16 discrete output channels for controlling external devices or processes. These outputs are divided into two sets, each consisting of eight channels.

Controls

The module operates on negative logic (also known as feed current logic), which means that when the logic signal is low, the output is active. It requires 1 output word to be addressed, making it easy to integrate into a control system or network.

Feature

The module has a discrete output voltage range of 10 to 60 V DC and an output voltage limit of 10.2 to 72 V. The module can withstand a maximum permanent output voltage of 72 V, ensuring durability and protection from voltage spikes. At 1 A load current, its pressure drop is less than or equal to 2 V.

Each module can handle A maximum load current of 12 A, while the load current of each group is limited to 6 A. In the event of a surge, the module can handle a surge current of up to 7.5A for 50 seconds. The response time of the module is very fast, and the transition time between state 1 and state 0 and between state 1 and state 1 is less than or equal to 0 ms.

trait

The module provides internal output protection through each set of 8 A fuses, ensuring the safety of the connected devices. The associated fuse is rated at 2 A for each discrete output point, while 8 A fuses are required for each set.

secure

Safety and isolation are critical in industrial applications and this module provides adequate protection. It provides 1 minute of isolation between the channel and the bus at 2500 Vrms DC and 1 minute of isolation between the two groups at 700 Vrms DC. These isolation measures help improve security and prevent interference between channels and groups.

compliance

The module is marked with CE certification, indicating that it complies with European safety standards. It also has the ability to send local signals through leds, including a green LED indicating bus communication activity, a red LED indicating external fault detection, and 16 green leds showing input status.

In terms of power requirements, the module consumes 160 mA of bus current. Power consumption is calculated as 1 W plus 1 V times the total load current of the module, ensuring efficient power management.

The Schneider Electric 2DDO140 module comes with an 84,300-year warranty and provides reliable performance, flexibility and safety for a wide range of industrial automation applications. Its rugged construction, high-speed response time and comprehensive protection features make it an excellent choice for controlling discrete outputs in industrial environments.
