140DDI35310
140DDI35310

140DDI35310 I/O 模块 SCHNEIDER

140DDI35310 I/O 模块 SCHNEIDER 【产品详情】 部件号140DDI35310制造者施耐德电气类型I/O 模块型#140-DDI-353-10保证2 年模块格式标准产品或组件类型低压直流离散输入模块离散输入编号32频道组4逻辑输入负面(来源)离散输入电压24 V 直流输入电压限制19.2 至 30 V保证电压状态1-30...-15 V 直流电压状态 0 保证-5...0 V

联系人:Sunny

手机:18059884797

QQ:3095989363

邮箱:xiongbagk@gmail.com

产品详情

140DDI35310 I/O 模块 SCHNEIDER




【产品详情】




部件号 140DDI35310

制造者 施耐德电气

类型 I/O 模块

型# 140-DDI-353-10

保证 2 年

模块格式 标准

产品或组件类型 低压直流离散输入模块

离散输入编号 32

频道组 4

逻辑输入 负面(来源)

离散输入电压 24 V 直流


输入电压限制 19.2 至 30 V

保证电压状态1 -30...-15 V 直流

电压状态 0 保证 -5...0 V 直流

当前状态 1 保证 >= 2.5 mA at US = - 14 V

当前状态 0 保证 <= 0.5 mA

寻址要求 2 个输入词

输入阻抗 2400欧姆

漏电流 200 mA (我们) = 5.5 V 和 Uin = 4 V

绝对最大输入 50 ms 衰减脉冲期间为 1 V

30 V 连续

响应时间 <= 从状态 1 到状态 1 的 0 ms


<= 从状态 1 到状态 0 的 1 ms

保护类型 通过电阻器限制提供输入保护

功耗 1.5 W + (0.26 x 点数)

组和总线之间的隔离 1780 分钟 1 Vrms

组间隔离 500 分钟 1 Vrms

本地信令 32 个 LED 绿色输入状态

检测到 1 个红色外部故障 (F)

存在 1 个 LED 绿色总线通信(活动)

标记 行政长官

总线电流要求 330毫安




140DDI35310  I/O 模块 SCHNEIDER





英文介绍





Part number 140DDI35310

Manufacturer Schneider Electric

Type I/O module

Type # 140-DDI-353-10

Guaranteed for 2 years

Module format standard

Product or Component type Low voltage DC discrete input module

Discrete input number 32

Channel group 4

Logic input negative (source)

Discrete input voltage 24 V DC


Input voltage limit 19.2 to 30 V

Guaranteed voltage state 1-30... -15 V DC

Voltage status 0 guaranteed -5... 0 V DC

Current status 1 Ensure that >= 2.5 mA at US = -14 V

Current status 0 must be <= 0.5 mA

Addressing requires 2 input words

Input impedance 2400 ohms

Leakage current 200 mA (us) = 5.5V and Uin = 4V

The absolute maximum input of 50 ms is 1 V during the attenuation pulse

30 V continuous

Response time <= 0 ms from state 1 to state 1


<= 1 ms from state 1 to state 0

Protection Type Input protection is provided through resistor limits

Power consumption 1.5W + (0.26x dots)

Isolation between group and bus 1780 minutes 1 Vrms

Isolation between groups 500 minutes 1 Vrms

Local signaling 32 LED green input status

1 red external fault detected (F)

There is 1 LED green bus communication (active)

Mark the chief executive

The bus current is 330 MA




140DDI35310  I/O 模块 SCHNEIDER
