140CRP31200 以太网 IP 远程EIO头模块
【产品详情】
远程EIO头模块140CRP31200由施耐德电气制造,用作本地昆腾EIO装置的头模块。EIO 头模块在本地机架上执行什么任务?Modicon 140CRP31200 头部 EIO 模块允许 PLC 与以太网网络通信,并实现对远程 I/O 设备的控制。这些产品在法国制造,专为物料搬运、包装和纺织机械使用而设计。它们提供MRO电气的2年保修。我们还提供来自其他制造商的I / O模块,如Modicon和ABB。
140CRP31200的特点
Modicon 140CRP31200 头部 EIO 模块的外部功能包括 LED、服务端口和互连端口、设备网络端口和第二个设备网络端口。指示灯位于模块的顶部正面。直接位于 LED I 下方的服务端口 (ETH1) 后跟互连端口 (ETH 2)。以下是 ETH 3 和 ETH 4 设备网络端口。为了保持设备的最佳运行状态,请在不使用连接时使用端口止动器。
这些端口允许对端口进行诊断,并允许访问外部工具和设备。它们提供与其他量子 EIO 的连接,并允许 I/O 通信。
Modicon 140CRP31200的主要功能是提供I / O扫描服务。I/O 扫描服务适用于远程 I/O 设备。I/O 设备可以位于远程 I/O 网络上,也可以位于具有远程 I/O 和分布式 I/O 设备的设备网络上。EIO 头模块使用菊花链环路拓扑来管理远程 I/O 网络。Modicon 140CRP31200连接到远程I/O网络主环。
其他以太网服务也可以由Modicon 140CRP31200执行。它可以执行诊断功能以及远程 I/O 设备的配置。
哪些功能块可以与 Modicon 140CRP31200 一起使用?140CRP31200 使用的四个功能块是 IU_ERIO、DROP 和 XDROP。
每个本地机架上只能配置一个 140CRP31200,因为它具有与网络上的以太网远程 I/O 设备通信的接口。
以太网远程 I/O 上的所有模块都可以通过 140CRP31200 EIO 头模块与以太网网络上的 PLC 通信,该模块能够确定它们之间的交换。
优势
Modicon 140CRP31200 EIO 头模块的任务是管理远程 I/O 设备。它还可以执行其他任务。140CRP31200 可帮助在 50 毫秒内恢复主环上遇到通信中断的模块。它通过使用 RSTP 或快速生成树协议来实现这一点。该模块还能够配置 IP 参数以及跌落时 I/O 单元的配置。它可以为多达 31 个远程 I/O 模块执行此操作。Modicon 140CRP31200 头部 EIO 模块允许分布式 I/O 和控制网络接入远程 I/O 网络。它通过互连通信路径执行此操作。Modicon 140CRP31200 磁头 EIO 模块还有助于实现热备用功能。
140CRP31200 以太网 IP 远程EIO头模块
【英文介绍】
The Remote EIO head module 140CRP31200 is manufactured by Schneider Electric and is used as the head module for local Quinten EIO devices. What tasks does the EIO header module perform on the local rack? The Modicon 140CRP31200 head EIO module allows the PLC to communicate with the Ethernet network and achieve control of remote I/O devices. Manufactured in France, these products are designed for material handling, packaging and textile machinery use. They come with a 2-year warranty on MRO Electric. We also offer I/O modules from other manufacturers such as Modicon and ABB.
140CRP31200 features
External functions of the Modicon 140CRP31200 head EIO module include leds, service ports and interconnect ports, device network ports, and a second device network port. The indicator light is located on the top front of the module. The service port (ETH1) directly below the LED I is followed by the interconnect port (ETH 2). The following are network ports on ETH 3 and ETH 4 devices. In order to maintain the best operating condition of the device, use the port stopper when not in use.
These ports allow diagnostics of ports and access to external tools and devices. They provide connectivity to other quantum EIOs and allow I/O communication.
The main function of Modicon 140CRP31200 is to provide I/O scanning service. The I/O scanning service is suitable for remote I/O devices. I/O devices can be located on a remote I/O network or on a device network with remote I/O and distributed I/O devices. The EIO header module uses the Daisy chain loop topology to manage the remote I/O network. The Modicon 140CRP31200 connects to the remote I/O network master ring.
Other Ethernet services can also be performed by Modicon 140CRP31200. It can perform diagnostic functions as well as configuration of remote I/O devices.
Which feature blocks can be used with Modicon 140CRP31200? The four functional blocks used by the 140CRP31200 are IU_ERIO, DROP and XDROP.
Only one 140CRP31200 can be configured on each local rack, as it has an interface to communicate with Ethernet remote I/O devices on the network.
All modules on the Ethernet remote I/O can communicate with the PLC on the Ethernet network through the 140CRP31200 EIO header module, which is able to determine the exchange between them.
advantage
The Modicon 140CRP31200 EIO header module is tasked with managing remote I/O devices. It can also perform other tasks. The 140CRP31200 helps to recover modules that experience a communication interruption on the main ring within 50 milliseconds. It does this by using RSTP or the Fast Spanning Tree protocol. The module is also capable of configuring IP parameters and the configuration of the I/O unit in case of a drop. It can do this for up to 31 remote I/O modules. The Modicon 140CRP31200 header EIO module allows distributed I/O and control networks to access remote I/O networks. It does this through the interconnect communication path. The Modicon 140CRP31200 head EIO module also facilitates the hot standby function.
