140CRA93200 带冗余电缆的连接器 适配器模块

【产品详情】

部件号 140CRA93200

制造者 施耐德电气

类型 I/O 模块

型# 140-CRA-932-00

保证 2 年

SAT 连接器 1 母头 F 型

140CRA93200是Modicon Quantum系列中的远程I/O头双通道模块。它设计用于与控制CPU模块一起安装在同一个背板上。该模块在两个模块（PCU和RIO分板模块）之间双向传输数据，这两个模块位于不同的背板中。为了互连此RIO头模块，使用同轴电缆网络以及至少一个其他RIO分支模块。这些产品在法国制造，专为物料搬运、包装和纺织机械使用而设计。它们提供MRO电气的2年保修。我们还提供来自其他制造商的I / O模块，如Modicon和ABB。

特征

Modicon 140CRA93200需要750 mA总线电流。典型功耗为3 W。此模块支持一个 ma CRP。该模块具有 31 次滴，可与昆腾 200 系列、500 系列、800 系列或 SY/MAX（任意组合）配合使用。有 64 个单词/丢弃和 64 个输出单词/删除。

此模块有 2 个端口/点，最多 32 个端口（16 个滴点），需要在 RIO 丢弃处使用 AS-P892-000 AS-J892-101/102 或 AS-J290-0X0。

Modicon 140CRA93200 远程 I/O 头使用 4 个 LED 指示灯。这些指示器是就绪、通信操作、错误 A 和错误 B。

模块顶部的正面是 LED 区域。LED 区域下方是带有连接器 A 和连接器 B 的 ROP 同轴连接器区域。侧面是版本标签。正面有一个可拆卸的铰链门。

如何使用 140CRA93200

此模块在本地量子 I/O 站中使用。要将140CRA93200插入本地工作站，第一步是调用总线编辑器，然后用鼠标左键标记工作站中的空闲插槽。将鼠标指向空闲插槽后，右键单击快捷菜单并选择新设备。

140CRA93200 带冗余电缆的连接器 适配器模块

【英文介绍】

Part number 140CRA93200

Manufacturer Schneider Electric

Type I/O module

Type # 140-CRA-932-00

Guaranteed for 2 years

SAT Connector 1 Female connector Type F

The 140CRA93200 is a remote I/O head dual-channel module in the Modicon Quantum family. It is designed to be mounted on the same backplane as the control CPU module. The module transmits data bidirectionally between two modules (PCU and RIO splitboard module), which are located in separate backplanes. To interconnect this RIO head module, a coaxial cable network and at least one other RIO branch module are used. Manufactured in France, these products are designed for material handling, packaging and textile machinery use. They come with a 2-year warranty on MRO Electric. We also offer I/O modules from other manufacturers such as Modicon and ABB.

trait

The Modicon 140CRA93200 requires 750 mA bus current. Typical power consumption is 3 W. This module supports an ma CRP. The module has 31 drops and can be used with the Quinten 200 series, 500 Series, 800 series or SY/MAX (any combination). There are 64 words/discard and 64 output words/delete.

This module has 2 ports/points up to 32 ports (16 drop points) and requires AS-P892-000 AS-J892-101/102 or AS-J290-0X0 at the RIO drop off point.

The Modicon 140CRA93200 remote I/O head uses 4 LED indicators. These indicators are ready, communication action, error A, and error B.

The front of the top of the module is the LED area. Below the LED area is the ROP coaxial connector area with connectors A and B. On the side is the version label. There is a detachable hinged door on the front.

How to use 140CRA93200

This module is used in a local quantum I/O station. To insert the 140CRA93200 into the local workstation, the first step is to call the bus editor, and then mark the free slots in the workstation with the left mouse button. After pointing the mouse to the free slot, right-click the shortcut menu and select new device.
