140CPU53414  处理器 586K 4MEG 控制专家编程软件管理

【产品详情】

特征

Modicon 140CPU53414 低端 CPU 模块的最大内部存储器为 800 kBytes。它配备了一个钥匙开关。它由控制专家编程软件管理。热备用拓扑不兼容，这是控制模块。它有两个通信端口，2个Modbus（RS-232），1个Modbus Plus（RS-485）。140CPU53414 的处理器是 inter 486，此特定模块所需的总线电流为 1250 mA。与本机一起使用的支撑模块的最大组合为 6。时钟速度为 66 MHz。它有一个数学处理器。

Modicon 140CPU53414具有无限的I / O字和最多2个I / O机架。它能够为每个网络最多输入 500 个输入和 500 个输出字。每个节点的最大字数为 30 输入和 32 输出，最大 DIO 丢弃/网络数为 64。它需要一个 3 V 锂电池。

如何使用 140CPU53414

低端 CPU 模块有几个通用组件。型号和型号说明都位于模块的顶部正面。型号和说明的正下方是 LED 显示屏。电池位于设备正面 LED 下方，后跟 140CPU53414 按键开关。按键开关下方是为内存端口和两个滑动开关指定的区域。两个滑动开关各有三个位置。左上角的开关是内存保护开关。使用在中间左边的位置或左下角的位置，没有内存保护。右侧滑动开关用于通信参数设置。其中也有三个。右上位置用于ASCII，中间位置用于RTU，右下位置用于mem。在内存端口和滑动开关下方，有两个连接器。第一个是Modus连接器，第二个是Modbus Plus连接器。有一个可拆卸的门可用于覆盖电池、钥匙开关和 Modbus 连接器。标签可以放在盖子内以进行识别。

140CPU53414  处理器 586K 4MEG 控制专家编程软件管理

【英文介绍】

trait

The Modicon 140CPU53414 low-end CPU module has a maximum internal memory of 800 kBytes. It is equipped with a key switch. It is managed by control expert programming software. The hot standby topology is not compatible. This is the control module. It has two communication ports, two Modbus (RS-232) and one Modbus Plus (RS-485). The processor for the 140CPU53414 is inter 486, and the bus current required for this particular module is 1250 mA. The maximum combination of support modules used with the machine is 6. The clock speed is 66 MHz. It has a math processor.

The Modicon 140CPU53414 has unlimited I/O words and up to 2 I/O racks. It is capable of up to 500 input and 500 output words per network. The maximum number of words per node is 30 input and 32 output, and the maximum number of DIO discard/network is 64. It requires a 3 V lithium battery.

How do I use 140CPU53414

Low-end CPU modules have several generic components. The model number and model description are located on the top front of the module. Directly below the model number and description is the LED display. The battery is located on the front of the device under the LED, followed by a 140CPU53414 key switch. Below the key switch is the area specified for the memory port and the two slide switches. Two sliding switches have three positions each. The switch in the upper left corner is the memory protection switch. Use in the left center position or the bottom left position with no memory protection. The right sliding switch is used to set communication parameters. There are three of them. The top right position is for ASCII, the middle position is for RTU, and the bottom right position is for mem. Under the memory port and slide switch, there are two connectors. The first is the Modus connector and the second is the Modbus Plus connector. There is a detachable door that can be used to cover the battery, key switch and Modbus connector. Labels can be placed inside the lid for identification.
