140CPU21304 处理器 768K 内存数学 MB+ 中央处理器
【产品详情】
Modicon 140 CPU 213 04是施耐德电气制造的量子CPU模块,用于量子自动化系统。CPU模块140 CPU 213 04在昆腾本地I/O背板上工作。这些产品在法国制造,专为物料搬运、包装和纺织机械使用而设计。它们提供MRO电气的2年保修。我们还提供来自其他制造商的CPU,如Modicon和ABB。
什么是 140 CPU 213 04 CPU?140 CPU 213 04是一个数字操作的电气系统。为了存储用户指令,它使用内部存储的可编程存储器。CPU 140 213 04能够用内部存储的用户指令做什么?Modicon 140 CPU 213 04能够执行特定的指令,如逻辑、过程排序、时序、耦合和算术。
上面列出的功能允许您控制各种类型的机器和过程。昆腾系统通过数字和模拟输出来实现这一点。
中央处理器有什么作用?昆腾 CPU 是总线主站。总线主站控制整个昆腾系统,包括系统的本地、远程和分布式 I/O。
140 CPU 的特点 213 04
Modicon 140 CPU 213 04 是一款控制器模块,配备 CPU 768 K RAM、MATH、Modbus Plus 和 Max IEC Program 606 K。该模块允许任意混合 64 k 离散。140 CPU 213 04在本地I/O背板上最多有64个输入和64个输出字。I/O 机架的最大数量为 2,需要扩展器。对于远程 I/O,140 CPU 213 04 每滴最多有 64 个输入和 64 个输出字。对于 31 CPU 140 213,最大远程丢弃次数为 04。分布式 I/O 每个系统最多有 3 个网络。每个网络的最大字数为 500 输入和 500 个输出,每个节点的最大单词数为 30 个输入和 30 个输出。看门狗定时器为250 ms,可通过软件调节。Modicon 140 CPU 213 04控制模块的逻辑求解时间为0.3 ms/k至1.4 ms/k。该装置的电池是 3 V 锂电池,使用寿命为 1200 mAh,保质期为 10 年,每年损失 5% 的容量。当电池负载时,电流(断电时)通常为5 μA,最大电流为110 μA。Modicon 140 CPU 213 04有一个串行Modus RS-232端口(9针D壳)。它具有 1 个网络 Modbus Plus (RS-485) 端口(9 针 D 外壳)。所需的总线电流为900 mA,功率分配为4.5 W。有一个时间时钟(+/- 8.0秒/天0 ...60°C)。NOM、NOE 和 MMS 模块的最大模块数(任意组合)。
140CPU21304 处理器 768K 内存数学 MB+ 中央处理器
【英文介绍】
The Modicon 140 CPU 213 04 is a quantum CPU module manufactured by Schneider Electric for use in quantum automation systems. CPU module 140 CPU 213 04 Works on the Quinten local I/O backplane. Manufactured in France, these products are designed for material handling, packaging and textile machinery use. They come with a 2-year warranty on MRO Electric. We also offer cpus from other manufacturers such as Modicon and ABB.
What is 140 CPU 213 04 CPU? The 140 CPU 213 04 is a digitally operated electrical system. To store user instructions, it uses internally stored programmable memory. What can CPU 140 213 04 do with internally stored user instructions? The Modicon 140 CPU 213 04 is capable of executing specific instructions such as logic, procedure ordering, timing, coupling, and arithmetic.
The functions listed above allow you to control various types of machines and processes. The Quinten system achieves this through both digital and analog outputs.
What does the CPU do? The Quinten CPU is the bus master. The bus master station controls the entire Quentin system, including the system's local, remote, and distributed I/O.
140 CPU features 213 04
The Modicon 140 CPU 213 04 is a controller module with CPU 768K RAM, MATH, Modbus Plus, and Max IEC Program 606K. The module allows arbitrary mixing 64k discrete. 140 CPU 213 04 The local I/O backplane has a maximum of 64 input and 64 output words. The maximum number of I/O racks is 2 and an extender is required. For remote I/O, 140 CPU 213 04 has a maximum of 64 input and 64 output words per drop. For 31 CPU 140 213, the maximum number of remote discard times is 04. Distributed I/O Up to 3 networks per system. The maximum number of words per network is 500 inputs and 500 outputs, and the maximum number of words per node is 30 inputs and 30 outputs. The watchdog timer is 250 ms and can be adjusted by software. The logic solution time of the Modicon 140 CPU 213 04 control module is 0.3 ms/k to 1.4 ms/k. The device's battery is a 3 V lithium battery with a service life of 1200 mAh and a shelf life of 10 years, losing 5% of its capacity every year. When the battery is loaded, the current (when powered off) is usually 5 μA, with a maximum current of 110 μA. The Modicon 140 CPU 213 04 has a serial Modus RS-232 port (9-pin D-shell). It has 1 network Modbus Plus (RS-485) port (9-pin D housing). The required bus current is 900 mA with a power distribution of 4.5 W. There is a time clock (+/- 8.0 seconds/day 0... 60°C). The maximum number of modules for NOM, NOE, and MMS modules (any combination).
140CPU21304 处理器 768K 内存数学 MB+ 中央处理器
