140CPU11304 SCHNEIDER 中央处理器 I/O 模块

【产品详情】

部件号 140CPU11304

制造者 施耐德电气

类型 中央处理器

型# 140-CPU-113-04

保证 2 年

您对这个中央处理器有什么期望？该单元可以从 I/O 模块中获取信息，然后使用该信息来管理您的过程。它使用您为特定应用程序编程的信息来执行此操作。输出信息将传输到您的过程，为您的过程提供所需的结果。该CPU的前面板由带有7个LED的显示块组成。这些指示灯是什么？七个 LED 包括就绪 LED，当上电诊断测试成功时，该 LED 会显示绿灯。跑执行程序时变为绿色的 LED。莫德布斯当 Modbus 端口有活动时，LED 变为绿色。Modbus Plus 当 Modbus Plus 端口有活动时，LED 显示绿色。梅姆·普尔特激活内存保护开关时，LED 变为橙色。蝙蝠低当备用电池需要更换或丢失时，LED 将变为红色。最后一个 LED 是错误 A LED，当 Modbus Plus 端口出现通信故障时，该 LED 变为红色。备用电池插槽也位于前面板上，还有一个滑动开关，用于选择 Modbus 端口通信参数和对内存进行写保护。它具有两个用于连接到Modbus总线的9路SUB-D母连接器和一个用于连接到Modbus Plus网络的9路SUB-D母连接器。可定制的识别标签在可拆卸的铰链门中可用。施耐德电气 140CPU31110 重 1.698 磅。

140CPU11304 SCHNEIDER 中央处理器 I/O 模块

【英文介绍】

Part number 140CPU11304

Manufacturer Schneider Electric

Type CPU

Type # 140-CPU-113-04

Guaranteed for 2 years

What do you expect from this CPU? The unit can take information from the I/O module and then use that information to manage your process. It does this using information that you have programmed for a particular application. The output information will be transferred to your process to provide the desired results for your process. The front panel of the CPU consists of a display block with 7 leds. What are these lights? The seven leds include the Ready LED, which displays a green light when the power-on diagnostic test is successful. The LED that turns green when running the program. When the Modbus port is active, the LED turns green. Modbus Plus When the Modbus Plus port is active, the LED displays green. When Mime Pulte activated the memory protection switch, the LED turned orange. When the backup battery needs to be replaced or lost, the LED will turn red. The last LED is Error A LED, which turns red when there is a communication failure in the Modbus Plus port. A spare battery slot is also located on the front panel, along with a slide switch for selecting Modbus port communication parameters and write protection of memory. It has two 9-way SUB-D female connectors for connecting to the Modbus bus and one 9-way SUB-D female connector for connecting to the Modbus Plus network. Customizable identification tags are available in removable hinged doors. The Schneider Electric 140CPU31110 weighs 1.698 pounds.

140CPU11304 SCHNEIDER 中央处理器 I/O 模块
