140XBP01000 SCHNEIDER 机架背板 - 10 插槽

140XBP01000 SCHNEIDER 机架背板 - 10 插槽 【产品详情】 Schneider Electric 背板,适合与 Modicon Quantum 系列一起使用,428(长)x 290mm(宽) - 140XBP01000使用 Schneider Electric 的此背板来组织输入/输出模块并将其连接到 PLC。此组件扩展了 PLC 的功能,由于它不会干扰安全流程,它适用

联系人:Sunny

手机:18059884797

QQ:3095989363

邮箱:xiongbagk@gmail.com

产品详情

140XBP01000  SCHNEIDER  机架背板 - 10 插槽




【产品详情】



Schneider Electric 背板,适合与 Modicon Quantum 系列一起使用,428(长)x 290mm(宽) - 140XBP01000

使用 Schneider Electric 的此背板来组织输入/输出模块并将其连接到 PLC。此组件扩展了 PLC 的功能,由于它不会干扰安全流程,它适用于工业安全应用。为便于使用,机架提供控制信号并分配操作所安装的模块所需的电源。此背板与 Schneider Electric 的 Modicon Quantum 系列的处理器和附件兼容,可控制复杂的连续或半连续工业过程。

特性和优势

• 坚固的金属框架,在恶劣环境中也能保证长寿命
• 包括螺纹孔,用于快速连接每个模块
• 随附接地接线端子,确保安全性
• 十个自由插槽,用于连接多个分布式、本地或远程输入/输出模块

应用

• 石化工业
• 水处理厂
• 水力发电
• 冶金行业

背板上是否有专用插槽?

否,此背板上没有专用插槽,这意味着您不会受限于安装模块的位置。建议您将电源模块插入极左槽,因为这有助于散热。

Schneider Electric Modicon Quantum 系列

Modicon Quantum 系列包含大量功能强大的处理器和附件,为复杂的连续或半连续工业过程提供了理想的解决方案。该高功率处理器优化循环时间,同时集成比之前更多的通信功能、诊断系统、存储器灵活性和数据存储。


140XBP01000是施耐德电气Modicon Quantum系列的一部分。此特定模块是一个背板,旨在托管昆腾自动化系统中的各种 I/O 模块、处理器和通信适配器。以下是基于与此类组件相关的典型规格和功能的概述和指南:


施耐德 140XBP01000 背板概述:


产品规格:


模块类型:底板(或机架)。

插槽:通常承载 10 个插槽,用于 I/O 模块、处理器和通信适配器。

总线电流供应:根据型号的不同,它通常支持托管模块的特定总线电流量。

建筑:针对某些配置中的冗余进行了优化。

通信:为模块提供通信总线,以便彼此之间和 CPU 之间通信。

物理性质:采用坚固的结构设计,适用于工业环境。

指南和安装:


选择:确保 140XBP01000 底板在尺寸、插槽数量和支持的模块方面适合您的系统。

放置:确定控制柜或面板中的合适位置。确保有足够的空间容纳所有相关模块、布线以及将来的任何添加或更改。

安装:使用适当的安装硬件将底板牢固地连接到面板或控制柜。如果使用DIN导轨安装,请确保其牢固夹紧。

模块插入:

在插入任何模块之前,请确保电源已关闭。

将模块连接器与底板插槽对齐。

轻轻但牢固地推动模块,直到其牢固地固定在插槽中。

布线:

按照产品技术文档中的说明将电源连接到底板。

确保所有模块都根据其各自的要求正确接线。

接地:必须将背板适当接地,以防止任何电气干扰并确保安全。

测试:安装、通电和接线后,打开系统。监控任何异常情况,并检查各个模块上的 LED 指示灯,以确保它们正常运行。

概述:


140XBP01000背板是施耐德电气Modicon Quantum系列的组成部分。作为 PLC 系统的基础,它托管和互连各种 I/O 模块、处理器和通信适配器,实现自动化系统内的高效无缝通信。其模块化设计确保了灵活性,可以根据系统需求轻松集成和扩展。




140XBP01000  SCHNEIDER  机架背板 - 10 插槽





英文介绍





The 140XBP01000 is part of Schneider Electric's Modicon Quantum series. This particular module is a backplane designed to host various I/O modules, processors, and communication adapters in Quinten Automation systems. The following is an overview and guidance based on typical specifications and features associated with such components:


Schneider 140XBP01000 Backplane Overview:


Product Specifications:


Module type: Chassis (or rack).

Slots: Typically hosts 10 slots for I/O modules, processors, and communication adapters.

Bus current supply: Depending on the model, it usually supports the specific bus current flow of the managed module.

Building: Optimized for redundancy in some configurations.

Communication: Provides a communication bus for modules to communicate with each other and the CPU.

Physical properties: Robust structural design for industrial environments.

Guide and installation:


Choose: Make sure the 140XBP01000 backboard fits your system in terms of size, number of slots, and supported modules.

Placement: Determine the appropriate location in the control cabinet or panel. Make sure there is enough room for all relevant modules, cabling, and any future additions or changes.

Installation: Securely attach the base plate to the panel or control cabinet using appropriate mounting hardware. If mounting using DIN rail, make sure it is firmly clamped.

Module insertion:

Before inserting any module, make sure the power is turned off.

Align the module connector with the baseboard slot.

Gently but firmly push the module until it is firmly secured in the slot.

Wiring:

Follow the instructions in the product technical documentation to connect the power supply to the baseplate.

Ensure that all modules are properly wired according to their respective requirements.

Grounding: The backplane must be properly grounded to prevent any electrical interference and ensure safety.

Test: After installation, power-on and wiring, turn on the system. Monitor for any anomalies and check the LED indicators on the individual modules to ensure they are functioning properly.

Overview:


The 140XBP01000 backplane is part of Schneider Electric's Modicon Quantum series. As the basis of the PLC system, it hosts and interconnects various I/O modules, processors and communication adapters, enabling efficient and seamless communication within the automation system. Its modular design ensures flexibility and can be easily integrated and extended according to system requirements.
