170ADI35000 动量控制器 用于分布式控制架构的控制器

☆型号：170ADI35000 动量控制器 用于分布式控制架构的控制器

【产品详情】

施耐德电气 Modicon Momentum 系列 - 用于分布式控制架构的控制器和 IP20 单块 I/O：

Momentum PLC 产品线的小尺寸和开放式架构使其在各种自动化应用中具有极强的通用性。Unity Momentum PLC 非常适合基于 PC 的控制、分布式控制、分布式 I/O 和传统的独立 PLC 控制。Momentum PLC 产品线包括 I/O 底座和通信适配器，它们可互换并卡在一起，以在整个控制系统生命周期内提供最佳灵活性。Modicon Unity Momentum CPU 使用以太网作为其通信主干网，提供实时控制的所有性能优势。Unity Momentum CPU 的开放式架构使其成为分布式 I/O 的通用控制器，与许多主要的现场总线和控制网络环境兼容。Unity Momentum CPU 中的集成以太网端口允许用户通过以太网执行各种功能，包括数据采集、点对点通信和 I/O 扫描。嵌入式网页允许使用标准 Web 浏览器从处理器读取状态和诊断信息。

Momentum Automation Platform 产品是模块化的。通信适配器和处理器适配器设计为在卡入 Momentum I/O 底座时作为功能模块工作。I/O 底座需要在其上组装某种类型的动量适配器，然后才能正常工作。I/O 底座可安装在紧凑型标准外壳中，可安装在 DIN 导轨或机柜中的面板上。它们从现场传感设备读取信息，并控制离散和模拟现场执行设备。

接线端子和母线可与底座一起使用，因此它们可用于支持 2 线、3 线和 4 线现场设备。I/O 现场设备和模块的电源通过三个 18 针接线端子和一个可选的 1 排、2 排或 3 排母线连接。端子连接器与模块电连接;选装母线不。母线排为现场设备提供通用连接，并用作保护性配电连接器。根据 I/O 基座及其所连接的现场设备的类型和数量，可以使用 1 排、2 排或 3 排母线排。接线端子和母线是单独订购的，不随 Momentum I/O 基座一起发货。它们有旋入式或弹簧夹式版本。

Disctrete I/O 基座功能：

IP20 整体 I/O 底座：为 Momentum 控制系统的其余部分提供基础，并用作通信适配器、处理器或选件适配器的安装底座。> 30 种 I/O 模块类型：模拟、分立、多功能等。

处理器适配器：使用单个本地 I/O 模块运行，或在具有多达 128 个模块、为 8192 个 I/O 点提供服务的系统中运行。内置分布式I/O通讯端口，Modbus TCP/IP-以太网或Modbus RS232串行通讯，嵌入式网页

选件适配器：为处理器提供额外的网络功能，以及时间时钟和电池备份

通信适配器：卡入任何 I/O 模块，包括 Modbus TCP/IP、Modbus Plus、FIPIO、INTERBUS、PROFIBUS DP 和 DeviceNet

Momentum 是一个灵活的模块化基础组件系列，可轻松卡接在一起，并可针对各种分布式 I/O 和控制应用进行配置。

应用：

基础设施和能源：RTU

楼宇和制造自动化

水处理

泵

石油与天然气

食品和饮料

配电

物料搬运

☆型号：170ADI35000 动量控制器 用于分布式控制架构的控制器

【英文介绍】

Schneider Electric Modicon Momentum Series - Controllers and IP20 Single block I/O for distributed control architectures:

The small size and open architecture of the Momentum PLC product line make it extremely versatile in a variety of automation applications. Unity Momentum PLC is ideal for PC-based control, distributed control, distributed I/O and traditional standalone PLC control. The Momentum PLC product line includes I/O bases and communication adapters that are interchangeable and clamped together to provide optimal flexibility throughout the control system life cycle. The Modicon Unity Momentum CPU uses Ethernet as its communications backbone, providing all the performance benefits of real-time control. The open architecture of the Unity Momentum CPU makes it a universal controller for distributed I/O, compatible with many major fieldbus and control network environments. The integrated Ethernet port in the Unity Momentum CPU allows users to perform a variety of functions over Ethernet, including data acquisition, point-to-point communication, and I/O scanning. Embedded Web pages allow status and diagnostic information to be read from the processor using a standard Web browser.

Momentum Automation Platform products are modular. The communication adapter and processor adapter are designed to work as functional modules when plugged into the Momentum I/O dock. The I/O base requires some type of momentum adapter to be assembled on it before it can function properly. The I/O base can be installed in a compact standard housing and can be mounted on a DIN rail or panel in the cabinet. They read information from field sensing devices and control discrete and analog field execution devices.

Terminals and bus bars can be used with the base, so they can be used to support 2 -, 3 -, and 4-wire field devices. The power supply for I/O field devices and modules is connected by three 18-pin terminals and an optional 1, 2, or 3 bar bus bar. The terminal connector is electrically connected to the module; Optional bus bar no. The bus bar provides universal connectivity for field equipment and is used as a protective distribution connector. Depending on the type and number of I/O bases and the field devices to which they are connected, 1, 2, or 3 bus bars can be used. Terminals and busbars are ordered separately and are not shipped with the Momentum I/O base. They are available in screw-in or spring-clip versions.

Disctrete I/O dock Features:

IP20 Integral I/O Base: Provides the base for the rest of the Momentum control system and is used as a mounting base for communication adapters, processors, or optional adapters. > 30 types of I/O modules: analog, discrete, multifunction, etc.

Processor adapter: Run with a single local I/O module or in a system with up to 128 modules serving 8192 I/O points. Built-in distributed I/O communication port, Modbus TCP/ IP-Ethernet or Modbus RS232 serial communication, embedded web pages

Optional adapter: Provides additional networking capabilities for the processor, as well as time clock and battery backup

Communication adapter: Card into any I/O module, including Modbus TCP/IP, Modbus Plus, FIPIO, INTERBUS, PROFIBUS DP, and DeviceNet

Momentum is a flexible family of modular base components that can be easily clipped together and configured for a variety of distributed I/O and control applications.

Applications:

Infrastructure and Energy: RTU

Building and manufacturing automation

Water treatment

pump

Oil and gas

Food and beverage

Power distribution

Material handling

☆型号：170ADI35000 动量控制器 用于分布式控制架构的控制器
