1.1文件的有效性

本文档适用于以下产品:

•VT-VPCD-1-1X/V0/1-0-1，材料号R901044346

•VT-VPCD-1-1X/V0/1-C-1，材料号R901102344

•VT-VPCD-1-1X/V0/1-D-1，材料号R901102347

•VT-VPCD-1-1X/V0/1-P-1，材料号R901089559

•VT-VPCD-1-1X/V100/1-0-1，物料号R901078493

2.1关于本章

本产品已按通用规则制造

当前的技术。然而，仍然存在人身伤害或财产损失的风险

如果不遵守本章和其中的安全说明，可能会损坏设备

在本文档中。

▶在使用本产品前，请仔细阅读本说明书

产品。

▶将本文档保存在所有用户都能访问的地方

次了。

▶将产品与所需文件一起交给第三方

派对。

2.2预期用途

本产品为电气元件。

您可以按照以下方式使用本产品:

•用于实现HS4或EO4控制所需的所有电气功能

具有电液旋转角度和压力控制以及为动力

变量轴向柱塞泵的局限性。

本产品仅供专业人士使用，不供私人使用。

按预期用途操作还意味着您已阅读并阅读过

完全理解本文档，特别是第2章“安全”

指令”。

2.3使用不当

除“预期用途”一节所述以外的任何用途均被视为不正当

因此是不允许的。

对于因使用不当而造成的损害，博世力士乐公司不承担任何责任。

因使用不当而产生的风险完全由用户承担。

下列，可预见的误用也不符合预期用途:

•使用控制电子元件来激活元件或设备，而不是

上述泵控制;

•如果您操作控制电子设备超出给定的性能限制和

工作条件，尤指规定的环境条件。

2.4人员素质

本文档中描述的活动要求具有基本的电气知识

和液压以及相关技术术语的知识。以确保

安全使用，因此这些活动只能由有资格的人员进行

或在合格人员的指导和监督下。

合格的人员是那些由于他们的专业培训，知识和

经验以及对相关法规的了解，能够评估所分配的工作

安全说明9/60

re30028 - b /09.13, VT-VPCD，博世力士乐公司

对他们，认识到潜在的危险，并制定适当的安全措施。合格的

人员必须遵守相关的专家规则并具备所需的专业知识。

对于液压产品，专业知识意味着，例如:

•能够阅读并完全理解液压回路图;

•完全理解与安全相关的相互关系

设备和

•了解液压元件的功能和结构
