Reliance Electric 45C940  输入模块

【产品详情】

45C940 装置是 Reliance Electric 公司为 Shark XL 系列创建的 115 VAC 输入模块。45C940 输入模块通常会在我们的库存中看到，即使原始制造商不再生产它。为方便起见，我们的网站旨在让您查看我们的产品（包括 45C940 输入模块）是否有库存。

Shark XL 系列中还有另外两个 115 VAC 输入模块可能对您的设施有用。 这些其他模块的产品编号为 45C941 和 45C942。点击与这些产品相关的链接，进入我们网站上的页面并了解有关它们的更多信息。

45C940 输入模块共有 8 个通道。本产品的标称电压可在 115 VAC 至 230 VAC 之间切换，输入电压范围为 85 至 264 VAC。 此输入模块的输入电流为 7 mA （100 VAC）。在工作状态方面，ON电压设置为85VAC以上，OFF电压为30VAC以下。与此相关的是，OFF到ON和ON到OFF的输入延迟时间为16毫秒或更短。该模块通道 1 的平均模块电流消耗为 1 mA，通道 2 和 3 的平均模块电流消耗为 0 mA。

45C940 输入模块的总重量为 0.44 磅（0.20 千克）。该设备的尺寸为 6 英寸（高）x 4.6 英寸（深）x 1.4 英寸（宽）。

 Reliance Electric 45C940  输入模块

【英文介绍】

The 45C940 unit is a 115 VAC input module created by Reliance Electric for the Shark XL series. The 45C940 input module will usually be seen in our inventory, even if the original manufacturer no longer produces it. For convenience, our website is designed to allow you to check whether our products, including the 45C940 input module, are in stock.

There are two other 115 VAC input modules in the Shark XL series that may be useful for your facility. These other modules have the product numbers 45C941 and 45C942. Click on the links related to these products to go to the pages on our website and learn more about them.

The 45C940 input module has eight channels. The nominal voltage of this product can be switched between 115 VAC and 230 VAC, and the input voltage range is 85 VAC to 264 VAC. The input current of this input module is 7 mA (100 VAC). In terms of working state, the ON voltage is set above 85VAC and the OFF voltage is set below 30VAC. Related to this, the input delay times for OFF to ON and ON to OFF are 16 milliseconds or less. The average module current consumption in channel 1 of this module is 1 mA, and the average module current consumption in channels 2 and 3 is 0 mA.

The 45C940 input module has a total weight of 0.44 lb (0.20 kg). The device measures 6 inches (height) x 4.6 inches (depth) x 1.4 inches (width).
