0-60031-5 驱动PMI模块 接收来自旋转变压器的数字信号

☆型号：0-60031-5   驱动PMI模块     接收来自旋转变压器的数字信号

【产品详情】

0-60031-5输入/输出分解器驱动PMI模块

0-60031-5是由Reliance制造的电路板，作为其各种驱动系统的组件,常见的是Automate系列驱动器。0-60031-5被视为过时零件, 不再生产。它通常被称为依赖部分。然而，公司结构的变化将Reliance Electric的这-部分与其他制造商合并。 您要更换的部件可能最初是从Baldor-Reliance或Asea Brown博韦里发货的。

0-60031-5是一个解析器和驱动I/O PMI模块。该组件有一个附加的窄面板, 其下半部分有两个母插头连接器。这些标记为“解析器反馈”和“驱

动/O”。该板还有九个led指示灯(装裱成两绿-红五绿- 红的图案。 )这些标记为fdbk ok、rpi、 mcr、 aux in1、aux in2、auxin3、 aux in4.

auxin5和aux out.

0-60031-5板组件包括一个位于后边缘中心的多针直角接口连接器。 它有3三个继电器、-个电感线圈、一个压器盘形电容器、压电容器晶体管、电阻器和二极管。该板有一个安装在散热器内的3000uV双极性运算放大器。 这位于左侧板边缘。它还拥有超过35个集成电路，包括现场可编程门阵列。

【英文介绍】

0-60031-5 I/O resolver Drives the PMI module

The 0-60031-5 is a circuit board manufactured by Reliance as a component in its various drive systems, most commonly the Automate series drives. 0-60031-5 is considered obsolete and is no longer produced. It is often referred to as the dependent part. However, changes in the corporate structure have merged this part of Reliance Electric with other manufacturers. The part you are replacing may have originally been shipped from Baldor-Reliance or Asea Brown Boveri.

0-60031-5 is a parser and driver I/O PMI module. The assembly has an attached narrow panel with two female plug connectors in its lower half. These are labeled "parser feedback" and "drive.

Move /O ". The board also has nine led indicators (mounted in a pattern of two green-red and five green-red). These are labeled fdbk ok, rpi, mcr, aux in1, aux in2, auxin3, aux in4.

auxin5 and aux out.

The 0-60031-5 board assembly includes a multi-pin right Angle interface connector located in the center of the back edge. It has three relays, an inductor coil, a voltage disk capacitor, voltage capacitor transistor, resistor and diode. The board has a 3000uV bipolar operational amplifier mounted inside a heat sink. This is on the left edge of the plate. It also has more than 35 integrated circuits, including field programmable gate arrays.
