MVI56E-MNET 服务器增强型网络接口模块 向后兼容性简化了迁移

【产品详情】

MVI56E-MNET 是一款 Modbus TCP/IP 客户端/服务器增强型网络接口模块，由 Allen-Bradley encompass 合作伙伴公司 ProSoft technology 制造。该模块使ControlLogix系统能够通过TCP/IP连接充当MODBUS主站或MODBUS客户端。

MVI56E-MNET向后兼容早期版本的MVI56E-MNET。这种向后兼容性简化了迁移，无需更改或修改现有的继电器梯形图逻辑或现有旧模块的当前配置。它支持 CIP 连接，允许通过 1756-ENBT、1756-EN2T 以太网通信适配器和 1756-CNB ControlNet 桥接模块跨多个网桥 I/P 和 ControlNet 网络进行远程配置和诊断访问。此外，该模块还支持 ProSoft Discovery Service （PDS），用于在以太网上自动定位 MVI56E 模块并指定临时 IP 地址。

该装置在运行时具有 30 克的冲击力，在不运行时具有 50 克的冲击力。它还具有 5 到 10 赫兹时 150 g 的振动。MVI56E-MNET 的相对湿度为 5% 至 95%，无冷凝。MVI56E-MNET配有五氧化二锂钒电池，可备份实时时钟，也可用于备份CMOS电池。预计电池将在模块的使用寿命内持续使用，在电池充满电之前，模块应连接电源至少 24 小时。使用充满电的电池，电池将提供足够CMOS和实时时钟21天的备用电源。MVI56E-MNET 支持带有 4 个字符字母数字显示屏的 LED 滚动诊断显示器。显示屏为状态消息提供标准英语，也用于显示报警数据以及处理器和网络通信状态。MVI56E-MNET还具有个性模块，该模块是工业紧凑型闪存卡，可存储完整的配置和以太网设置。

MVI56E-MNET 服务器增强型网络接口模块 向后兼容性简化了迁移

【英文介绍】

The MVI56E-MNET is a Modbus TCP/IP client/server Enhanced networking interface module manufactured by Allen-Bradley encompass Partner company ProSoft technology. This module enables the ControlLogix system to act as a MODBUS master or MODBUS client over a TCP/IP connection.

MVI56E-MNET is backward compatible with earlier versions of MVI56E-MNET. This backward compatibility simplifies migration without changing or modifying existing relay ladder logic or the current configuration of existing legacy modules. It supports CIP connectivity, allowing remote configuration and diagnostic access across multiple bridge I/P and ControlNet networks via 1756-ENBT, 1756-EN2T Ethernet communication adapters and 1756-CNB ControlNet bridge modules. In addition, the module supports ProSoft Discovery Service (PDS) for automatically locating the MVI56E module and specifying a temporary IP address on the Ethernet network.

The device has an impact force of 30 grams when in operation and 50 grams when not in operation. It also has a vibration of 150 g at 5 to 10 Hz. MVI56E-MNET has a relative humidity of 5% to 95% and is non-condensing. The MVI56E-MNET is equipped with a lithium vanadium pentoxide battery that backs up a real-time clock and can also be used to back up a CMOS battery. The battery is expected to last for the lifetime of the module, and the module should be connected to a power source for at least 24 hours before the battery is fully charged. Using a fully charged battery, the battery will provide enough CMOS and real-time clock backup power for 21 days. The MVI56E-MNET supports an LED rolling diagnostic display with a 4-character alphanumeric display. The display provides standard English for status messages and is also used to display alarm data and the status of processor and network communications. The MVI56E-MNET also features a personality module, which is an industrial compact flash memory card that can store complete configurations and Ethernet Settings.

MVI56E-MNET 服务器增强型网络接口模块 向后兼容性简化了迁移
