MVI69-MCM 主/从网络接口模块具有 1 个插槽

【产品详情】

ProSoft MVI69-MCM Modbus 网络接口模块是 CompactLogix inRAx Modbus RTU 主/从通信模块，它提供 Allen Bradley PAC（可编程自动化控制器）和 MicroLogix 可编程逻辑控制器 （1769-LRP） 与 Modbus 连接兼容设备之间的接口。MVI69-MCM 安装在 1769 机箱的单个机箱插槽上，它使用梯形逻辑在模块和处理器之间快速无缝地传输数据。MVI69-MCM 在 5 V DC 时的最大背板电流为 800 毫安。

它有一个不支持握手配置的 RS-232 CFG 端口，它还具有 2 个 RS-232 应用端口（P1 和 P2），支持握手协议，并与背板具有 500 伏光隔离。该模块随附 RJ-45 （DB-9F） 电缆和 RJ-45 到 DB-9M 配置电缆，并具有显示电池、应用程序和串行端口状态的前面板 LED 指示灯。MVI69-MCM 的数据传输速率为 110 Kilo 波特至 115 Kilobaud，具有无、偶数或奇数奇偶校验选择，数据以浮点数据格式传输。它支持主/从通信协议，配置数据是直接提供给模块的文本文件。MVI69-MCM 的工作温度范围为 0 至 60 摄氏度（32 至 140 华氏度），非冷凝相对湿度范围为 5% 至 95%，并通过了 GOST-R、DNV、c-UL-us 和 CE 认证。

MVI69-MCM 主/从网络接口模块具有 1 个插槽

【英文介绍】

The ProSoft MVI69-MCM Modbus Network interface module is a CompactLogix inRAx Modbus RTU master/slave communication module. It provides an interface between Allen Bradley PAC (Programmable Automation Controller) and MicroLogix Programmable Logic Controller (1769-LRP) and Modbus connected compatible devices. The MVI69-MCM is mounted on a single chassis slot in the 1769 chassis, and it uses ladder logic to transfer data quickly and seamlessly between modules and processors. The MVI69-MCM has a maximum backplane current of 800 mA at 5 V DC.

It has an RS-232 CFG port that does not support a handshake configuration, it also has 2 RS-232 application ports (P1 and P2) that support the handshake protocol, and has 500 volt optical isolation from the backplane. The module comes with an RJ-45 (DB-9F) cable and an RJ-45 to DB-9M configuration cable, and features front panel LED indicators that show battery, application, and serial port status. The MVI69-MCM has data transfer rates of 110 Kilobaud to 115 Kilobaud, with zero, even, or odd parity options, and data is transferred in floating-point data format. It supports master/slave communication protocols, and configuration data is a text file provided directly to the module. The MVI69-MCM operates in a temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) and a non-condensing relative humidity range of 5 to 95 percent and is GOST-R, DNV, c-UL-us and CE certified.

MVI69-MCM 主/从网络接口模块具有 1 个插槽
