MVI56-PDPS处理器，具有兼容的电源

【产品详情】

系统需求

MVI56-PDPS模块最低硬件要求如下

软件组件:

罗克韦尔自动化ControlLogix™处理器，具有兼容的电源

电源和机架上的一个免费插槽，用于MVI56-PDPS模块。的

模块需要800mA的可用功率。

罗克韦尔自动化RSLogix 5000编程软件版本2.51或

更高。

罗克韦尔自动化RSLinx通信软件

奔腾®II最低450mhz。Pentium III 733 MHz(或更高)

最少128 mb的RAM，建议256 mb的RAM

MVI56-PDPS♦ControlLogix平台从这里开始

Profibus DP从站通信模块

ProSoft Technology, Inc.第10页

* 100 mb的可用硬盘空间(根据应用程序的不同，可以更多)

需求)

256色VGA图形适配器，最低分辨率为800 x 600(真彩色)

1024 × 768(推荐)

超级终端或其他终端仿真程序。

注意:模块可安装在本地机架或远程机架。对于远程机架安装，模块

需要以太网/IP或ControlNet与处理器通信。

1.2包装内容

以下组件包含在MVI56-PDPS模块中，它们是

所有这些都是安装和配置所需的。

重要:在开始安装之前，请确认以下所有项目都已安装

礼物。

数量。部件名称部件编号部件描述

1 MVI56 -

pdp

模块

MVI56-PDPS Profibus DP从站通信模块

电缆15号，RS232

零调制解调器

RS232连接到CFG端口

1线缆14号线缆，RJ45到

DB9公适配器

电缆

对于DB9连接到模块的端口

MVI56-PDPS处理器，具有兼容的电源

【英文介绍】

System requirement

The minimum hardware requirements of the MVI56-PDPS module are as follows

Software components:

Rockwell Automation ControlLogix™ processor with compatible power supply

Power supply and a free slot in the rack for the MVI56-PDPS module. the

The module requires 800mA of available power.

Rockwell Automation RSLogix 5000 Programming software version 2.51 or

Higher.

Rockwell Automation RSLinx communication software

Pentium ®II starts at 450mhz. Pentium III 733 MHz(or higher)

Minimum 128 mb of RAM, 256 mb of RAM recommended

The MVI56-PDPS♦ControlLogix platform starts here

Profibus DP Slave station communication module

ProSoft Technology, Inc. P. 10

* 100 mb of free hard disk space (more depending on the application)

Needs)

256-color VGA graphics adapter with a minimum resolution of 800 x 600(true color)

1024 x 768(recommended)

Hyperterminal or other terminal emulator.

Note: Modules can be mounted on local racks or remote racks. For remote rack mounting, modules

Ethernet /IP or ControlNet is required to communicate with the processor.

1.2 Packaging Contents

The following components are included in the MVI56-PDPS module, they are

All of this is required for installation and configuration.

Important: Before starting the installation, make sure that all of the following items are installed

A gift.

The number. Component Name Component Number Component Description

1 MVI56 -

pdp

module

MVI56-PDPS Profibus DP Slave station communication module

Cable number 15, RS232

Null modem

The RS232 connects to the CFG port

1 Cable 14 Cable, RJ45 to

DB9 male adapter

cable

For DB9 connect to the port of the module
