MVI56-S3964R 网络接口模块 协议模块

【产品详情】

 ProSoft MVI56-S3964R Siemens 3964R 网络接口模块具有 1 个插槽和梯形逻辑数据传输。该模块具有本地或远程机架类型和 512 字节的最大传输大小。

ProSoft MVI56-S3964R 是用作 Siemens 3964R 网络接口模块的协议模块。ProSoft Technology 制造的该协议模块用于在任何 ControlLogix 处理器（如 1756-L1、1756-L1Mx、1756-L55 或 1756-L6x）与具有西门子 3964R 通信功能的任何其他设备之间进行点对点通信。基本上，它支持Allen-Bradley PLC和西门子设备之间的通信，因为3964R协议是由西门子公司发明的。Prosoft MVI56-S3964R 实质上采用点对点协议，具有读写功能。它执行密件抄送校验和以确保传输的安全性。设备使用 2 个独立运行的 RS-232 或 RS-422 通信端口与设备通信。

该模块在 ControlLogix 机箱中占用 1 个插槽，并且与 1756 背板兼容。它在 5 伏直流电下消耗 800 mA 或在 24 伏直流电下消耗 3 mA。ControlLogix 处理器将模块识别为 I/O 模块，并允许其访问处理器内存，以实现快速可靠的数据传输。为了使数据传输走上正轨，使用了梯形逻辑。为了简化实施过程，在用户应用程序中随 Prosoft MVI56-S3964R 协议模块一起提供了示例梯形图程序。可以发送/接收的最大传输数据包为 512 字节。通信活动通过 LED 发出信号，也可以通过确认报文获得，因此总有一种方法可以提取有关数据传输质量的信息。Prosoft MVI56-S3964R 软件包包括 2 根电缆、1 个适配器和 1 张 CD，以及协议模块本身。

MVI56-S3964R 网络接口模块 协议模块

【英文介绍】

ProSoft MVI56-S3964R Siemens 3964R Network interface module with 1 slot and ladder logic data transmission. The module has a local or remote rack type and a maximum transfer size of 512 bytes.

ProSoft MVI56-S3964R is a protocol module used as a Siemens 3964R network interface module. This protocol module is manufactured by ProSoft Technology for use in any ControlLogix processor (such as the 1756-L1, 1756-L1Mx, 1756-L55 or 1756-L6x) with a Siemens 3964R Communication features point-to-point communication between any other devices. Basically, it supports communication between Allen-Bradley PLC and Siemens equipment, as the 3964R protocol was invented by Siemens. Prosoft MVI56-S3964R essentially uses the peer-to-peer protocol, with read and write functions. It performs the BCC checksum to ensure the security of the transmission. The device communicates with the device using two independently operated RS-232 or RS-422 communication ports.

This module occupies one slot in the ControlLogix chassis and is compatible with the 1756 backplane. It consumes 800 mA at 5 volts DC or 3 mA at 24 volts DC. The ControlLogix processor recognizes the module as an I/O module and allows it access to processor memory for fast and reliable data transfer. In order to keep the data transmission on track, ladder logic is used. To simplify implementation, a sample ladder diagram program is provided in the user application along with the Prosoft MVI56-S3964R protocol module. The maximum transmission packet that can be sent/received is 512 bytes. Communication activity is signaled through leds and can also be obtained through confirmation messages, so there is always a way to extract information about the quality of data transmission. The Prosoft MVI56-S3964R package includes 2 cables, 1 adapter, and 1 CD, as well as the protocol module itself.
