MVI56-MBP 双端口网络接口模块 逻辑数据传输

【产品详情】

 ProSoft MVI56-MBP Modbus Plus 双端口网络接口模块具有 1 个插槽和梯形逻辑数据传输。该模块具有本地或远程机架类型和 57600 波特率。

Prosoft MVI56-MBP是一款Modbus Plus通信模块。该模块是 Allen-Bradley 的 ControlLogix PLC 的支持设备。它有助于将这些处理器与使用 Modbus Plus 协议的其他设备连接起来。MVI56-MBP 支持主站和从站设备，可轻松连接到 Modicon 处理器和许多其他 Modbus 设备。它充当 ControlLogix 背板和 Modbus Plus 网络之间的网关。该设备具有4000字寄存器的存储器，其主要功能是以异步方式在PLC和Modbus Plus网络之间交换数据。此外，MVI56-MBP可以配置为PLC的从设备，PLC必须从模块的存储器中读取或写入数据。它通常用于连接两个品牌的工业网络，例如，Allen-Bradley PLC 与 Modicon PLC 的连接，以及继电器、驱动器、电源监控设备和类似的 Modbus Plus 讲话设备与 ControlLogix 背板的连接。

MVI56-MBP Modbus Plus 通信模块具有可充电锂钒电池，能够在该模块内备份数据 21 天。它备份CMOS和实时时钟。安装模块时，电池应充电 21 小时。它经过精心设计，可在模块的整个生命周期内使用。如果设备超过 <> 天没有电源，模块将返回默认 BIOS 设置。

MVI56-MBP 双端口网络接口模块 逻辑数据传输

【英文介绍】

The ProSoft MVI56-MBP Modbus Plus dual port network interface module has 1 slot and ladder logic for data transmission. The module is available in local or remote rack types and 57,600 baud rates.

Prosoft MVI56-MBP is a Modbus Plus communication module. This module is a support device for Allen-Bradley's ControlLogix PLC. It helps connect these processors to other devices that use the Modbus Plus protocol. The MVI56-MBP supports both master and slave devices and can easily connect to Modicon processors and many other Modbus devices. It acts as a gateway between the ControlLogix backplane and the Modbus Plus network. The device has a memory of 4000 word registers and its main function is to exchange data between the PLC and Modbus Plus network in an asynchronous manner. In addition, the MVI56-MBP can be configured as a slave device for a PLC, which must read or write data from the module's memory. It is commonly used to connect two brands of industrial networks, for example, Allen-Bradley PLC to Modicon PLC, and relays, drivers, power monitoring devices, and similar Modbus Plus talking devices to the ControlLogix backplane.

The MVI56-MBP Modbus Plus communication module has a rechargeable lithium-vanadium battery that is capable of backing up data within the module for 21 days. It backs up CMOS and real-time clock. When installing the module, the battery should be charged for 21 hours. It is carefully designed to be used throughout the module's life cycle. If the device is without power for more than <> days, the module returns to the default BIOS Settings.

MVI56-MBP 双端口网络接口模块 逻辑数据传输
