MVI56-DNPSNET 以太网服务器网络接口模块

【产品详情】

 ProSoft MVI56-DNPSNET DNP 3.0 以太网服务器网络接口模块具有 1 个插槽和梯形逻辑数据传输。该模块具有本地或远程机架类型和最多 500 个模拟输入。

MVI56-DNPSNET 模块是 DNP 3.0 服务器以太网通信模块。它是 ProSoft Technology 的 inRAx 产品系列的一部分。DNP 是一种开放式通信协议，旨在实现石油和天然气、水、废水和电力公用事业行业中使用的系统之间的互操作性。MVI56-DNPSNET 模块允许 ControlLogix 处理器与支持 DNP 协议的现场设备进行通信。DNP 提供可靠高效的通信，还支持时间戳和 TRBE 进行实时数据传输。该模块随附的组件包括用于 PC 和模块的 CFG 端口之间通信的 RS232 零调制解调器，以及 RJ45 转 DB9 公头适配器电缆和 inRAx 解决方案 CD。该模块已获得各种机构的批准，包括 CB 安全、CE、RoHS 和 GOST-R 机构。MVI56-DNPSNET模块的典型应用包括石化、SCADA和DCS以及电力和配电应用。

MVI56-DNPSNET 模块可以安装在本地或远程机架中。当模块安装在远程机架中时，需要与处理器进行以太网或 ControlNet 通信 MVI56-DNPSNET 模块在 32 伏直流电下的电流负载为 3 毫安，在 5.1 伏直流电下的电流负载为 800 毫安。电源导体和接地导体的推荐最小横截面积分别为 1.3 平方毫米和 4 平方毫米。模块上提供 LED 指示灯，用于显示模块状态、应用状态、背板传输状态和串行活动状态。不可更换的可充电电池为实时模块时钟和CMOS提供备用电源。充满电的电池可提供长达 21 天的备用电源。

MVI56-DNPSNET 以太网服务器网络接口模块

【英文介绍】

ProSoft MVI56-DNPSNET DNP 3.0 Ethernet Server network interface module with 1 slot and ladder logic data transfer. The module has local or remote rack types and up to 500 analog inputs.

The MVI56-DNPSNET module is the Ethernet communication module of the DNP 3.0 server. It is part of ProSoft Technology's inRAx product family. DNP is an open communication protocol designed to enable interoperability between systems used in the oil and gas, water, wastewater, and electric utility industries. The MVI56-DNPSNET module allows the ControlLogix processor to communicate with field devices that support the DNP protocol. DNP provides reliable and efficient communication and also supports time stamps and TRBE for real-time data transfer. The components included with the module include an RS232 null modem for communication between the PC and the module's CFG port, as well as an RJ45 to DB9 male adapter cable and an inRAx solution CD. The module has been approved by various agencies, including CB Safety, CE, RoHS and GOST-R agencies. Typical applications of the MVI56-DNPSNET module include petrochemical, SCADA and DCS, and power and distribution applications.

The MVI56-DNPSNET module can be installed locally or in a remote rack. Ethernet or ControlNet communication with the processor is required when the module is mounted in a remote rack. The MVI56-DNPSNET module has a current load of 3 MA at 32 volts DC and 800 MA at 5.1 volts DC. The recommended minimum cross-sectional areas for the power conductor and the ground conductor are 1.3 square millimeters and 4 square millimeters, respectively. LED indicators are provided on the module to display module status, application status, backplane transmission status and serial activity status. The non-replaceable rechargeable battery provides backup power for the real-time module clock and CMOS. A fully charged battery provides backup power for up to 21 days.

MVI56-DNPSNET 以太网服务器网络接口模块
