MVI56-BSAPS 串行从站模块

【产品详情】

模块

MVI56-BSAPSMVI56布里斯托尔巴布科克串行从机模块允许罗克韦尔自动化ControlLogix I/O兼容

处理器接口容易与布里斯托尔巴布科克系列通信设备。

特点和优点

MVI56-BSAPS模块作为输入/输出模块

模块之间的BSAP网络和罗克韦尔

自动化底板。该模块充当从属模块

从BSAP主设备接收命令。的

从ControlLogix处理器传输的数据是

与BSAP网络上的操作异步。一个

模块内部数据库交换数据

在处理器和BSAP网络之间。

BSAP在轮询环境中运行。中的每个链接

网络支持不同的轮询速率。选择的费率

取决于各种应用程序相关的因素。

BSAP的设计和实施是根据

国际标准的功能层

组织(ISO)模型。因为每一层

独立于其相邻层，两者同步

并可采用异步传输方式支持。

通用规范

•单槽- 1756背板兼容

•模块被识别为输入/输出

模块，可以访问处理器内存

处理器和模块之间的数据传输

•梯形逻辑用于数据之间的传输

模块和处理器。包括示例梯子文件。

•从配置文本中获取配置数据

文件下载到模块。样例配置文件

包括

•本地或远程机架

硬件规格

规范描述

底板当前

MVI56-BSAPS 串行从站模块

【英文介绍】

module

MVI56-BSAPSMVI56 Bristol Babcock serial slave module allows Rockwell Automation ControlLogix I/O compatibility

The processor interfaces easily with Bristol Babcock series communication devices.

Features and advantages

The MVI56-BSAPS module serves as the input/output module

Modules between BSAP network and Rockwell

Automated backboard. This module acts as a slave module

Receive commands from the BSAP master. the

The data transferred from the ControlLogix processor is

Asynchronous with operations on the BSAP network. single

The internal database of the module exchanges data

Between the processor and the BSAP network.

BSAP runs in a polling environment. Each link in

The network supports different polling rates. Selected rate

Depends on a variety of application-specific factors.

The design and implementation of BSAP is based on

International standard functional layer

Organization (ISO) model. Because every layer

Independent of its adjacent layers, the two are synchronized

And can be supported by asynchronous transmission mode.

General specification

• Single slot - 1756 backplane compatible

• Modules are identified as input/output

Module that can access processor memory

Data transfer between processors and modules

• Ladder logic is used for data transmission

Modules and processors. Includes sample ladder files.

• Obtain the configuration data from the configuration text

File download to module. Example configuration file

include

• Local or remote rack

Hardware specification

Specification description

Backplane current
