MVI56-ADM 可编程应用开发模块 梯形逻辑数据传输功能

【产品详情】

 ProSoft MVI56-ADM 'C' 可编程应用开发模块具有 1 个插槽和梯形逻辑数据传输功能。该模块具有本地或远程机架类型和 110-115,200 波特率。

inRAx-ProSoft Technology MVI56-ADM 应用开发模块是可编程的，主要用于 Allen-Bradley/Rockwell Automation ControlLogix 系列模块。该模块具有 110 至 115 波特的通信速度和 800 毫安（5.1 伏直流）/3 毫安（24 伏直流）的背板电流负载。MVI56 应用开发模块与 ControlLogix 模块兼容，用户可以在 ControlLogix 平台上安装自定义的“C”程序。ADM 提供了一个灵活而强大的解决方案，用于加速自定义 ASCII 数据通信或为专有算法提供保护。MVI56-ADM 模块用作输入/输出模块，它习惯于在使用处理器内存的同时在模块和处理器之间传输数据。“C”可编程模块具有 2 个串行端口 （ADM）、处理器背板接口、API 库、可移植代码、数字 Mars C++ 编译器，是定制应用的绝佳串行解决方案。ProSoft MVI56-ADM 模块属于 ProSoft Technology 模块的 ADM 系列。

MVI56-ADM 模块具有调试/配置端口、CFG 端口、串行端口 P1/P2 和应用专用端口（PRT1 和 PRT2）。每个端口用于连接模块的电缆长度必须为 9 米，并且必须有一根 6 英尺长的 RS-232 电缆进行配置。除此之外，这些模块还包括用于显示模块状态、背板传输状态、串行端动和应用程序状态的 LED 指示灯。该模块与单插槽 1756 背板兼容。该模块在 0 至 60 摄氏度（32 至 140 华氏度）的温度范围内运行，相对湿度为 5% 至 95%。该模块的存储温度范围在 -40 至 85 摄氏度（-40 至 185 华氏度）之间，运行时可承受 30 G 的冲击，不运行时可承受 50 G 的冲击。除此之外，该模块可以在 5 至 10 赫兹频率下承受 150 G 的振动。MVI56-ADM 模块旨在满足 ATEX 指令、CE、GOST-R、C/UL 1 级、韩国 KC 注册以及其他一些相关标准和认证的所有要求。

MVI56-ADM 可编程应用开发模块 梯形逻辑数据传输功能

【英文介绍】

ProSoft MVI56-ADM 'C' programmable application development module with 1 slot and ladder logic data transfer function. The module is available in local or remote rack types and 110-115,200 baud rates.

The inRAx-ProSoft Technology MVI56-ADM application development module is programmable and is mainly used for Allen-Bradley/Rockwell Automation ControlLogix series modules. The module has a communication speed of 110 to 115 baud and a backplane current load of 800 mA (5.1 V DC) /3 MA (24 V DC). The MVI56 application development module is compatible with the ControlLogix module and allows users to install custom "C" programs on the ControlLogix platform. ADM provides a flexible and powerful solution for speeding up custom ASCII data communication or providing protection for proprietary algorithms. The MVI56-ADM module is used as an input/output module and is used to transferring data between the module and the processor while using processor memory. With 2 serial ports (ADM), processor backplane interface, API library, portable code, digital Mars C++ compiler, the "C" programmable module is an excellent serial solution for custom applications. The ProSoft MVI56-ADM module belongs to the ADM series of ProSoft Technology modules.

The MVI56-ADM module has a debug/configuration port, a CFG port, serial ports P1/P2, and application-specific ports (PRT1 and PRT2). The cable length for each port to connect the module must be 9 meters, and there must be a 6-foot long RS-232 cable for configuration. In addition, these modules include LED indicators for module status, backplane transmission status, serial terminating, and application status. The module is compatible with the single-slot 1756 backplane. The module operates in a temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) with a relative humidity of 5 to 95 percent. The module has a storage temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit) and can withstand a shock of 30 G when in operation and 50 G when not in operation. In addition, the module can withstand 150 G of vibration at 5 to 10 Hz frequencies. The MVI56-ADM module is designed to meet all requirements of the ATEX Directive, CE, GOST-R, C/UL Level 1, Korean KC registration, and a number of other relevant standards and certifications.

MVI56-ADM 可编程应用开发模块 梯形逻辑数据传输功能
