PLX31-EIP-MBTCP 双向通信网关模块 可以涂覆保形涂层

☆型号：PLX31-EIP-MBTCP  双向通信网关模块 可以涂覆保形涂层

【产品详情】

制造者 Allen-Bradley/罗克韦尔自动化

系列 PLX3 网关

零件编号 PLX31-EIP-MBTCP

产品类型 网关模块

SD卡 支持

以太网协议 支持

Modbus TCP/IP协议 支持

振动 10 至 150 赫兹时为 5 G

额定电压 24 伏直流电

工作温度 -13 至 158 华氏度

关于PLX31-EIP-MBTCP

PLX31-EIP-MBTCP 设备是由 Allen-Bradley 和 ProSoft Technology 制造的双向通信网关模块。PLX31-EIP-MBTCP 网关模块专门用作以太网到 Modbus TCP/IP 网关，允许将数据从以太网设备传输到 Modbus TCP/IP 设备，反之亦然。PLX31-EIP-MBTCP 网关模块具有 10,000 个 16 位寄存器，因此可以一次处理大量数据。SD 卡是此网关模块的可选功能，该模块具有一个 SD 卡插槽，允许网关模块使用 SD 卡来存储其配置文件和灾难恢复。PLX31-EIP-MBTCP网关模块的尺寸约为5.38 x 1.99 x 4.38英寸。

Allen-Bradley 和 ProSoft Technology PLX31-EIP-MBTCP 网关模块的额定电压为 24 伏直流电，工作电压范围为 10 至 36 伏直流电。它支持正极端子、负极端子和 GND 端子。PLX31-EIP-MBTCP 网关模块可在 -13 至 158 华氏度或 -25 至 70 摄氏度的温度范围内运行，其存储温度范围为 -40 至 176 华氏度或 -40 至 80 摄氏度。在操作和储存中，环境湿度水平应在大约 5% 到 95% 之间，没有冷凝。PLX31-EIP-MBTCP网关模块可以涂覆保形涂层，以便在恶劣环境中提供保护。在运行过程中，该 ProSoft Technology 网关模块可以在 10 至 150 赫兹的频率下承受高达 5 G 的振动。

☆型号：PLX31-EIP-MBTCP  双向通信网关模块 可以涂覆保形涂层

【英文介绍】

Manufacturer Allen-Bradley/ Rockwell Automation

Series PLX3 gateway

Part number PLX31-EIP-MBTCP

Product Type Gateway module

SD Card support

Ethernet protocol support

Modbus TCP/IP protocol support

5 G at 10 to 150 Hz

Rated voltage 24 volts DC

Operating temperature -13 to 158 degrees Fahrenheit

About PLX31-EIP-MBTCP

The PLX31-EIP-MBTCP device is a two-way communication gateway module manufactured by Allen-Bradley and ProSoft Technology. The PLX31-IP-MBTCP Gateway module is specifically used as an Ethernet-to-Modbus TCP/IP gateway, allowing data to be transferred from an Ethernet device to a Modbus TCP/IP device and vice versa. The PLX31-EIP-MBTCP gateway module has 10,000 16-bit registers, so it can process large amounts of data at once. An SD card is an optional feature of this gateway module, which has an SD card slot that allows the gateway module to use the SD card to store its configuration files and disaster recovery. The PLX31-EIP-MBTCP gateway module measures approximately 5.38 x 1.99 x 4.38 inches.

Allen-Bradley and ProSoft Technology PLX31-IP-MBTCP gateway modules are rated at 24 volts DC and operate in a voltage range of 10 to 36 volts DC. It supports positive terminals, negative terminals and GND terminals. The PLX31-EIP-MBTCP gateway module can operate in a temperature range of -13 to 158 degrees Fahrenheit or -25 to 70 degrees Celsius, and its storage temperature range is -40 to 176 degrees Fahrenheit or -40 to 80 degrees Celsius. During operation and storage, the ambient humidity level should be between approximately 5% and 95%, with no condensation. The PLX31-EIP-MBTCP gateway module can be coated with a conformal coating to provide protection in harsh environments. During operation, the ProSoft Technology gateway module can withstand vibrations of up to 5 G at frequencies from 10 to 150 Hz.

☆型号：PLX31-EIP-MBTCP  双向通信网关模块 可以涂覆保形涂层
