TP2020SS USB电源开关 适用于可能遇到高容性负载和短路的应用

☆型号：TP2020SS USB电源开关 适用于可能遇到高容性负载和短路的应用

【产品详情】

TPS202x 系列配电开关适用于可能遇到高容性负载和短路的应用。这些器件是 50m N 沟道 MOSFET 高侧电源开关。该开关由与 5V 逻辑和 3V 逻辑兼容的逻辑使能端控制。栅极驱动由内部电荷泵提供，该电荷泵设计用于控制电源开关的上升时间和下降时间，以较大限度地减小开关期间的电流浪涌。电荷泵无需外部元件，允许采用低至2.7 V的电源供电。

当输出负载超过限流阈值或出现短路时，TPS202x 会切换到恒流模式，从而将过流 （OC） 逻辑输出拉至低电平，从而将输出电流限制在安全水平。当连续的重过载和短路增加开关的功率耗散，导致结温升高时，热保护电路会关闭开关以防止损坏。一旦器件充分冷却，就会自动从热关断中恢复。内部电路确保开关保持关断状态，直到存在有效的输入电压。

TPS202x 器件的区别仅在于短路电流阈值。TPS2020限值为 0.3A 负载，TPS2021限值为 0.9A 负载，TPS2022限值为 1.5A 负载，TPS2023限值为 2.2A 负载，TPS2024限值为 3A 负载（请参阅）。TPS202x 采用 8 引脚小型集成电路 （SOIC） 封装和 8 引脚双列直插式封装 （DIP），工作结温范围为 -40°C 至 125°C。

33m（5V 输入）高侧 MOSFET 开关

短路和热保护

过流逻辑输出

工作范围 . . .2.7 V 至 5.5 V

逻辑电平使能输入

典型上升时间 . . .6.1 毫秒

欠压闭锁

最大待机电源电流 . . .10 微安

无漏源背栅二极管

采用 8 引脚 SOIC 和 PDIP 封装

环境温度范围：-40°C至85°C

2kV 人体模型、200V 机器模型 ESD 保护

UL 列名 - 文件编号E169910

☆型号：TP2020SS USB电源开关 适用于可能遇到高容性负载和短路的应用

【英文介绍】

The TPS202x series distribution switches are suitable for applications where high capacitance loads and short circuits may be encountered. These devices are 50m N channel MOSFET high-side power switches. The switch is controlled by a logic enable terminal compatible with 5V logic and 3V logic. The gate drive is provided by an internal charge pump designed to control the rise time and fall time of the power switch to minimize electrical surges during switching. The charge pump requires no external components and allows power supply as low as 2.7V.

When the output load exceeds the current-limiting threshold or a short circuit occurs, the TPS202x switches to constant current mode, which pulls the overcurrent (OC) logic output to a low level, thereby limiting the output current to a safe level. When the continuous heavy overload and short circuit increase the power dissipation of the switch, resulting in a high junction temperature, the thermal protection circuit closes the switch to prevent damage. Once the device is sufficiently cooled, it automatically recovers from the thermal shutdown. The internal circuit ensures that the switch remains off until an effective input voltage is present.

The TPS202x devices differ only in the short circuit current threshold. The TPS2020 limit is 0.3A load, the TPS2021 limit is 0.9A load, the TPS2022 limit is 1.5A load, the TPS2023 limit is 2.2A load, and the TPS2024 limit is 3A load (see). The TPS202x is available in an 8-pin small integrated circuit (SOIC) package and an 8-pin dual-in-line package (DIP) with an operating junction temperature range of -40°C to 125°C.

33m (5V input) high-side MOSFET switch

Short circuit and thermal protection

Overstream logic output

Working range... 2.7V to 5.5V

Logic level Enables input

Typical rise time... 6.1 ms

Undervoltage block

Max standby power supply current... 10 microamps

Drain-source-free backgate diode

Available in 8-pin SOIC and PDIP packages

Ambient temperature range: -40°C to 85°C

2kV human body model, 200V machine model ESD protection

UL Column name - File number E169910
