DS200AAHAG2A  驱动板 传统系列模块

【产品详情】

DS200AAHAG2A是MARK V LM Speedtronic ARCNET HUB LAN驱动板。该板最初由 GE 创建，但现在是一个传统系列模块，不再获得 GE 的任何支持。尽管如此，当市场上出现可用盈余时，AX Control 确实会尝试保持该板的库存。

该DS200AAHAG2A也称为 ARCNET 连接板 （AAHA）。它被制成 Mark V 系统控制面板的一部分。AAHA 板能够将外部设备连接到控制引擎，该引擎是 <R> Core 的一部分。它使用 ARCNET 连接来实现此目的。<R>内核实际上将其中两块板用于略有不同的目的。一块 AAHA 板用于促进不同操作员界面和 <R> 内核之间的 Stage Link。另一块AAHA板用于向COREBUS网络授予<R>核心通信。建立此连接将鼓励控制引擎与 <R> 内核内的 I/O 内核之间的通信。该板还使用 APL 连接器连接到 PANA 板。

DS200AAHAG2A（AAHA）的特点如下：

两个连接端口。

右侧标记为 P1 和 P2 的另外两个端口是 ARCBNC-B 和 ARCBNC-A 端口。

P1 连接器下方是 2PL 连接。该板的右下角是一个 APL 10 针连接器，用于在 AAHA 板和 <R> 内核内包含 ARCNET 驱动程序的板之间提供通信链路。

DS200AAHAG2A  驱动板 传统系列模块

【英文介绍】

The DS200AAHAG2A is a MARK V LM Speedtronic ARCNET HUB LAN driver board. The board was originally created by GE, but is now a legacy series module that no longer receives any support from GE. Nonetheless, AX Control does try to keep that board in stock when there is an available surplus in the market.

The DS200AAHAG2A is also known as the ARCNET Connector Board (AAHA). It is made as part of the Mark V system control panel. The AAHA board is able to connect external devices to the control engine, which is part of the <R> Core. It uses ARCNET connections for this purpose. <R> The kernel actually uses two of these boards for slightly different purposes. An AAHA board is used to facilitate Stage Link between different operator interfaces and <R> kernels. Another AAHA board is used to grant <R> core communication to the COREBUS network. Establishing this connection encourages communication between the control engine and the I/O kernel within the <R> kernel. The board is also connected to the PANA board using APL connectors.

DS200AAHAG2A (AAHA) features the following:

Two connection ports.

The other two ports on the right, labeled P1 and P2, are ARCBNC-B and ARCBNC-A.

Below the P1 connector is a 2PL connection. The lower right corner of the board is an APL 10-pin connector that provides a communication link between the AAHA board and the board containing the ARCNET driver within the <R> kernel.
