1769-L18ER-BB1B 采用紧凑且经济高效的封装

【产品详情】

技术参数 1769-L18ER-BB1B

产品系列： 5370 L1

最大 I/O 数 支持的模块： 8 个模块 - 点 I/O

以太网节点： 8 节点

以太网拓扑： 线性、星形和设备级环网 （DLR）

通讯端口： （1）USB;（2） 以太网 I/P

最大 I/O 数 支持的银行： 不支持

不。任务： 32 任务

不。每个任务的程序数： 100

1769-L18ER-BB1B 是由罗克韦尔自动化的一个部门 Allen Bradley 设计和制造的 CompactLogix 系列装置。1769-L18ER-BB1B 采用紧凑且经济高效的封装，具有高性能控制功能和通信元件。1769-L18ER-BB1B 归类于 CompactLogix 5370 L1 可编程自动化控制器。它支持多达 32 个控制器任务，并具有 100 个连续或定期任务。1769-L18ER-BB1B 具有两个连接到 EtherNet/IP 网络的以太网端口。这些端口用于传输与控制器的嵌入式交换机相同的网络流量。控制器使用一个 IP 地址。1769-L18ER-BB1B 还具有一个用于临时连接的 USB 端口。此控制器最多支持 4 个以太网节点。1769-L18ER-BB1B 支持多达 256 个控制器连接，集成了 16 个直流数字输入和 16 个数字输出。DIN导轨安装的1769-L18ER-BB1B控制器最多支持8个本地POINT I/O模块，并使用1734背板。其嵌入式 I/O 模块提供 16 个灌电流数字输入点和 16 个拉电流数字输出点。它支持 DLR 网络功能，增强了通信和连接的弹性。最大插槽数为 32 个，该装置还配备了一个可选的非易失性存储器，该存储器具有 1784-SD1 卡，支持高达 1GB 的内存，并且随该装置一起提供。该装置还支持具有约 2GB 可用内存的 1784-SD2 卡。

1769-L18ER-BB1B 专为满足用户需求而设计，可确保高性能和具有成本竞争力的运动解决方案。在部署模块之前，请务必检查控制器内存估算器，以确保有足够的内存来执行应用程序的控制器程序。1769-L18ER-BB1B 具有 0.5 MB 用户内存。它有一个内部储能装置，无需额外的电池。此外，1769-L18ER-BB1B 可以读取继电器梯形图、结构化文本、功能块和 SFC 编程语言。工作温度应在 -20 至 60 摄氏度（-4 至 140 华氏度）之间，IEC 60068-2-30 非冷凝相对湿度在 5% 至 95% 之间，以实现最佳控制器性能和产品寿命。

1769-L18ER-BB1B 主存储器具有 0.5 MB 的嵌入式用户存储器和 1GB 非易失性存储器，由预装的 1784-SD1 安全数字 （SD） 卡提供。使用 1784-SD2 可以更换此非易失性存储器并将其升级到 2GB 存储器。除了内置内存区域。它还带有 16 个 24VDC 数字输入和 16 个 24VDC 数字输出通道。这款紧凑型控制器最多可安装八 （8） 个 1734 点 I/O 模块，以扩展内置 I/O 功能。该控制器最多可以处理32个控制器任务，无论是连续型还是周期型，每个控制器任务最多可以包含100个程序。

为了与编程设备、监控和数据采集 （SCADA） 系统、人机界面 （HMI） 设备进行通信，该控制器内置两 （2） 个以太网通信接口，可用作具有单个 IP 地址的嵌入式以太网交换机。这些端口支持线性、设备级环网 （DLR） 和传统启动拓扑。该设备最多可建立 32 个插座和 256 个控制器连接，从而实现复杂的通信功能。除以太网端口外，该控制器还具有一 （1） 个 USB 端口，可用于编程、硬件配置和在线编辑，但工业通信和数据交换除外。
