SP2403 先进变频器 提供灵活的电机控制

【产品详情】

产品概述：

SP2403 是由工业自动化解决方案领域公认的领导者 Control Techniques 生产的先进变频器。该器件提供灵活的电机控制，以满足各种应用的需求，包括正常和重载操作。

主要规格：

制造商： Control Techniques

产品编号： SP2403

类型：交流驱动器

保修：2年

输入电压：380 - 480VAC

框架尺寸： 2

性能指标：

正常值班操作：

最大持续电流：29 A

典型电机输出功率：15 kW 或 20 HP

重型作业：

最大持续电流：25 A

典型电机输出功率：11 kW 或 10 HP

操作条件：

SP2403 设计用于在高达 40°C （104°F） 和海拔 1000m 的条件下提供额定连续输出电流，开关频率为 3.0 kHz。如果超过这些参数，则需要降额。有关如何降额的详细信息，建议用户查阅驱动器随附的 Unidrive SP 用户指南。

电源和输入电流：

输入电流受电源电压和阻抗的影响。值得注意的是，所列输入电流为典型值，并假定电源条件平衡。实际电流可能因这些因素而异。

安装和外壳：

尺寸 1 至 6 的 Unidrive SP 驱动器可以使用右侧支架进行表面安装或穿板安装。但是，尺寸 0 只能进行表面贴装。驱动器的机柜不是按分类的防火机柜。因此，对于在美国的安装，建议使用 NEMA 12 外壳，而在美国以外，应遵循特定标准，例如光伏逆变器的 IEC 62109-1。

EMC滤波器：

内置EMC滤波器是驱动器的组成部分，可显著减少向线路电源的射频发射。通常建议用户将此过滤器保留在原位，除非某些条件需要将其移除。

SP2403 先进变频器 提供灵活的电机控制

【英文介绍】

Product Overview:

The SP2403 is an advanced frequency converter produced by Control Techniques, a recognized leader in industrial automation solutions. The device provides flexible motor control to meet the needs of a variety of applications, including normal and heavy duty operations.

Main specifications:

Manufacturer: Control Techniques

Product Number: SP2403

Type: AC drive

Warranty: 2 years

Input voltage: 380-480VAC

Frame size: 2

Performance index:

Normal duty operation:

Maximum continuous current: 29 A

Typical motor output: 15 kW or 20 HP

Heavy duty operation:

Maximum continuous current: 25 A

Typical motor output: 11 kW or 10 HP

Operating conditions:

The SP2403 is designed to provide rated continuous output current at up to 40°C (104°F) and an altitude of 1000m, with a switching frequency of 3.0 kHz. If these parameters are exceeded, derating is required. For more information on how to derate, users are advised to consult the Unidrive SP user guide that comes with the drive.

Power supply and input current:

The input current is affected by the voltage and impedance of the supply. It is important to note that the input currents listed are typical values and that the power supply conditions are assumed to be balanced. Actual currents may vary depending on these factors.

Installation and housing:

Unidrive SP drives in sizes 1 to 6 can be surface-mounted or through-plate mounted using the right bracket. However, size 0 can only be surface-mounted. The drive cabinets are not classified as fire resistant cabinets. Therefore, for installations in the United States, NEMA 12 housing is recommended, while outside the United States, specific standards should be followed, such as IEC 62109-1 for photovoltaic inverters.

EMC Filter:

The built-in EMC filter is an integral part of the driver and significantly reduces RF emission to the line power supply. Users are generally advised to leave this filter in place unless certain conditions require its removal.
