0-60028-2 用于自动的栅极驱动器接口模块

0-60028-2是Reliance Electric的模块，用于公司的各种驱动器，最常见的是Automax SA 3000。

0-60028-2用作栅极驱动器接口模块。它不再生产。该组件由带有附加前面板的矩形电路板组成.面板顶部和底部设计有固定螺钉，一旦模块安装到机架系统中，即可将模块锁定到位。它还具有一个标记为“OK”的绿色 LED 指示灯，以及一个本地电源（母头）接口连接器。在这些组件下方，该板有六组光纤链路 （hp 9717 R-2521） 一个接一个地排列。这些都标记为XMT或RCV，每个集合也标记为（从上到下）为U（+），U（-），V（+），V（-），W（+）和W（-）。面板标有电路板用途和电路板ID号。

连接到 0-60028-2 模块的电路板组件装有直角接口连接器，位于其后边缘。它有晶体管、电阻器、电容器、二极管、跳线开关和四十多种集成电路。电路板的正面和背面都用于组件.后板表面主要装有电容器和电阻器。

0-60028-2  栅极驱动器接口模块

【英文介绍】

0-60028-2 Interface module for automatic gate driver

The 0-60028-2 is a module of Reliance Electric used in the company's various drives, the most common being the Automax SA 3000.

0-60028-2 Used as gate driver interface module. It no longer produces. The component consists of a rectangular circuit board with an attached front panel. Screws are designed at the top and bottom of the panel to lock the module into place once it is installed into the rack system. It also features a green LED indicator marked "OK", and a local power (female) interface connector. Beneath these components, the board has six sets of fiber links (hp 9717 R-2521) arranged one after the other. These are all labeled XMT or RCV, and each set is also labeled (from top to bottom) as U (+), U (-), V (+), V (-), W (+), and W (-). The panel is marked with board purpose and board ID number.

The board assembly connected to the 0-60028-2 module is fitted with a right Angle interface connector, located on the rear edge. It has transistors, resistors, capacitors, diodes, jumper switches and more than forty integrated circuits. Both the front and back of the board are used for the components. The rear surface of the plate is mainly equipped with capacitors and resistors.
