0-51378-25 栅极耦合板 信实电气开发和分销

【产品详情】

0-51378-25模块由信实电气开发和分销，作为栅极耦合板。0-51378-25栅极耦合板也以Baldor Reliance和Asea Brown Boveri的名义分发。

0-51378-25栅极耦合板设计为适合Reliance Electric整流器堆栈顶部的完美尺寸。 信实电气自己的86466-58R模块是与0-51378-25栅极耦合板兼容的整流器堆栈的一个例子。如果您需要购买整流器堆栈以及 0-51378-25 栅极耦合板，

在0-51378-25栅极耦合板的中间，您会发现一个由小金属棒固定的大型变压器。该变压器的每个角都有一个标签，分别是“H1”、“H2”、“X1”和“X2”。在大型变压器旁边，您可以找到一些连接到电路板的电阻器。在板子的两个角上，每个角都有一个孔。这些孔意味着插入大螺钉，将0-51378-25栅极耦合板连接到信实电气整流器堆栈的顶部。

0-51378-25 栅极耦合板的重量约为 0.10 磅或 0.045 千克。

0-51378-25 栅极耦合板 信实电气开发和分销

【英文介绍】

The 0-51378-25 module was developed and distributed by Reliance Electric as a gate coupling plate. The 0-51378-25 gate coupled plates were also distributed under the names Baldor Reliance and Asea Brown Boveri.

The 0-51378-25 gate coupling board is designed to fit perfectly on top of Reliance Electric's rectifier stack. Reliance Electric's own 86466-58R module is an example of a rectifier stack compatible with 0-51378-25 gate coupling plates. If you need to purchase a rectifier stack and 0-51378-25 gate coupling plate,

In the middle of the 0-51378-25 gate coupling plate, you will find a large transformer held in place by a small metal bar. Each corner of the transformer is labeled "H1", "H2", "X1" and "X2". Next to the large transformer, you can find some resistors connected to the circuit board. There is a hole in each of the two corners of the board. These holes are meant to insert large screws to connect the 0-51378-25 gate coupling plate to the top of the Reliance rectifier stack.

The 0-51378-25 gate coupling plate weighs approximately 0.10 lb or 0.045 kg.
