☆型号：IS200ISBEH2A 重型涡轮机所需的保护 操作员界面
【产品详情】
IS200ISBEH2A是通用电气为Mark VI系统制造的组件。MKVI 是 Speedtronic 最后的燃气/蒸汽轮机管理系统之一，被认为是重型涡轮机所需的保护、控制和监控的完整解决方案，包括所有硬件和软件。MKVI采用HMI（操作员界面）构建，该界面基于运行Microsoft Windows平台的PC，并预装了CIMPLICITY图形显示器以及其他专有软件。HMI直接连接到中央控制模块，在那里对系统进行所有控制和保护。这允许替换或重新初始化 HMI，而不会影响正在运行的进程。
IS200ISBEH2A 是一个 ISbus 扩展板，用作发送/接收连接器，通常设计用于直接与控制组件背板 （IS200CABP） 上的 J11A 本地 ISBus 接口连接器配接。该板具有一个 DATEL DC/DC 转换器，具有 18V 至 36V 输入、5V 输出 @ 1A。该板有多个连接器，包括两个标有 P1A 和 P1B 的插头。有两个端子排，每个端子排有两个位置，位于电路板的相对两侧，以及两个光纤连接器（R 和 T）。该板有四个传导传感器（E1 到 E4）。该板有一个三位跳线开关。该板有一个标有“JP1-Interlock Bypass”的信息框，其中包含以下信息：1-2 Unbypassed，2-3 Bypassed。该板有三个 LED 和八个集成电路。该板还具有电阻器、二极管和电容器。
☆型号：IS200ISBEH2A 重型涡轮机所需的保护 操作员界面
【英文介绍】
The IS200ISBEH2A is a General Electric component for the Mark VI system. MKVI is one of Speedtronic's last gas/steam turbine management systems and is considered a complete solution for the protection, control and monitoring required for heavy-duty turbines, including all hardware and software. MKVI is built with an HMI (Operator Interface) based on a PC running the Microsoft Windows platform and pre-installed with CIMPLICITY graphics displays and other proprietary software. The HMI connects directly to the central control module, where all control and protection of the system is carried out. This allows the HMI to be replaced or reinitialized without affecting the running process.
The IS200ISBEH2A is an ISbus expansion board that serves as a send/receive connector and is typically designed to interface directly with the J11A local ISBus interface connector on the control component backplane (IS200CABP). The board has a DATEL DC/DC converter with 18V to 36V input and 5V output @1A. The board has multiple connectors, including two plugs labeled P1A and P1B. There are two terminal blocks, each with two positions, located on opposite sides of the board, and two fiber optic connectors (R and T). The board has four conduction sensors (E1 to E4). The board has a three-position jumper switch. The board has an information box labeled "JP1-Interlock Bypass", which contains the following information: 1-2 Unbypassed, 2-3 Bypassed. The board has three leds and eight integrated circuits. The board also has a resistor, diode and capacitor.
☆型号：IS200ISBEH2A 重型涡轮机所需的保护 操作员界面
