GPIB-VXI 用于VXIbus的GPIB接口 可用作系统资源管理器

【产品详情】

National Instruments 用于 VXIbus 的 GPIB-VXI GPIB 接口

NI GPIB-VXI 是 为 VXIbus 设计的 GPIB 接口。该接口设计用于连接VXIbus和IEEE-488 （GPIB）总线。NI GPIB-VXI提供GPIB协议和信号与VXIbus协议和信号的透明转换。通过该接口，GPIB控制器可用于控制VXIbus仪器，因为它控制GPIB仪器。

GPIB-VXI接口经过预配置，可用作系统资源管理器。该型号提供 VXIbus 自检、启动配置和初始化功能。此外，它还执行 VXIbus 的插槽 0 相关服务。如果用户想使用另一个RM进行操作，GPIB-VXI的这些插槽0和RM功能可能会被禁用。NI GPIB-VXI GPIB 接口的设计完全符合 VXIbus 规范。该型号具有三个可编程 VXIbus 中断处理程序和 4 MB 双端口存储器。

该GPIB接口可以执行专门设计的软件模块，称为Code Instruments。GPIB-VXI的前面板包含五个连接器：串行端口、触发输入、触发输出、GPIB接口和外部CLK10 I/O。此外，还提供一个可配置的复位按钮，可配置为复位背板和/或GPIB-VXI。NI GPIB-VXI中的ROM量可以在512 KB到1 MB之间调整。该装置出厂时可使用 512 KB 的 EPRROM 运行。EPROM用于存储和操作设备的固件。但是，还提供了四个额外的插槽用于EPROM扩展。

GPIB-VXI 用于VXIbus的GPIB接口 可用作系统资源管理器

【英文介绍】

National Instruments GPIB-VXI GPIB interface for VXIbus

NI GPIB-VXI is a GPIB interface designed for VXIbus. This interface is designed to connect VXIbus and IEEE-488 (GPIB) buses. NI GPIB-VXI provides transparent conversion of GPIB protocols and signals to VXIbus protocols and signals. Through this interface, the GPIB controller can be used to control the VXIbus instrument as it controls the GPIB instrument.

The GPIB-VXI interface is preconfigured to function as a system resource manager. This model provides VXIbus self-test, startup configuration, and initialization functions. In addition, it performs slot 0-related services for VXIbus. These slot 0 and RM functions of GPIB-VXI may be disabled if the user wants to operate with another RM. The NI GPIB-VXI GPIB interface is designed to comply fully with the VXIbus specification. This model has three programmable VXIbus interrupt handlers and 4 MB dual-port memory.

This GPIB interface can execute a specially designed software module called Code Instruments. The front panel of the GPIB-VXI contains five connectors: serial port, trigger input, trigger output, GPIB interface, and external CLK10 I/O. In addition, a configurable reset button is provided that can be configured to reset the backplane and/or GPIB-VXI. The amount of ROM in NI GPIB-VXI can be adjusted from 512 KB to 1 MB. The device can be run from the factory with 512 KB of EPRROM. EPROM is used to store and operate the firmware of the device. However, four additional slots are provided for EPROM expansion.

GPIB-VXI 用于VXIbus的GPIB接口 可用作系统资源管理器
