GPIB-SPRC-B 高性能 IEEE 488 接口板  数据传输可实现最佳性能

【产品详情】

National Instruments GPIB-SPRC-B IEEE 488 接口板

特征：

Sun SPARCstation 的 GPIB 接口

S 总线 DVMA 数据传输可实现最佳性能

传输速率 - 使用 1EEE 488.1 的 1.4 MB/s;HS488 为 3.6 MB/s

完全兼容 IEEE 488.2

National Instruments GPIB-SPRC-B 是一款低成本、高性能的 IEEE 488 接口套件，适用于配备 S 总线插槽的 Sun SPARCstation 系列工作站。NI TNT4882C ASIC 使 SB-GPIB/ TNT 成为 最 高性能 的 IEEE 488.2 接口 板。TNT4882C芯片执行 IEEE 488.2 标准要求的基本 IEEE 488 讲话器、侦听器和控制器功能。借助 TNT4882C 和 S 总线直接虚拟内存访问 （DVMA） 传输，使用 IEEE 488.1 3 线握手，数据传输速度可以达到 1.4 MB/s。TNT4882C可以显著提高关联的多任务 Solaris 驱动程序软件的吞吐量。SB-GPIB/TNT 还实现了高速 GPIB 协议 （HS488），因此数据传输速度可以超过 3.6 MB/s。

GPIB-SPRC-B是一款高性能GPIB接口板。GPIB-SPRC-B接口板由美国国家仪器公司组装。NI GPIB-SPRC-B 的 部件号 为 776789-01 可 订购。GPIB-SPRC-B板属于National Instruments的GPIB系列板。NI GPIB-SPRC-B 板 卡 使用 NI-488.2 驱动 软件 运行 。该接口板可与LabVIEW和LabWindows/CVI一起使用，用于推荐的软件。

NI GPIB-SPRC-B与Solaris操作系统兼容。GPIB-SPRC-B接口板由SB-GPIB/TNT板和用于Solaris的NI-488.2组成。SB-GPIB/TNT 可以插入单宽主 S 总线插槽中。常规 IEEE 488 电缆可以将电路板连接到多达 14 个设备。一台计算机中可以插入多个 SB-GPIB/TNT 板来控制多个设备。

该接口板的设计符合IEEE 488.2标准兼容性。GPIB-SPRC-B接口板提供最大的GPIB数据传输速率。GPIB-SPRC-B板可以执行超过3.6 MB/s的高速（HS-488）传输速率。该板支持超过 1.4 MB/s 的 IEEE 488.1 数据速率。National Instruments GPIB-SPRC-B具有软件控制的配置选项。NI GPIB-SPRC-B 不需要任何跳线。

此 IEEE 488 接口板专为提供 S 总线 DVMA 数据传输而开发。该板采用TNT4882C ASIC芯片构建。GPIB-SPRC-B可以控制信号，用于渲染快速GPIB事件的服务。NI GPIB-SPRC-B 接口 板 在 制造 时 与 所有 旧 版本 的 SB- GPIB 接口 板 完全 兼容 软件。

GPIB-SPRC-B 高性能 IEEE 488 接口板  数据传输可实现最佳性能

【英文介绍】

National Instruments GPIB-SPRC-B IEEE 488 interface board

Features:

GPIB interface of Sun SPARCstation

S-bus DVMA data transfer for optimal performance

Transfer rate - 1.4MB /s using 1EEE 488.1; HS488 is 3.6 MB/s

Fully compatible with IEEE 488.2

The National Instruments GPIB-SPRC-B is a low-cost, high-performance IEEE 488 interface kit for the Sun SPARCstation family of workstations equipped with an S-bus slot. The NI TNT4882C ASIC makes SB-GPIB/ TNT the most high-performance IEEE 488.2 interface board. The TNT4882C chip performs the basic IEEE 488 speaker, listener, and controller functions required by the IEEE 488.2 standard. With TNT4882C and S-bus direct Virtual Memory access (DVMA) transmission, data transfer speeds can reach 1.4 MB/s using IEEE 488.1 3-wire handshake. TNT4882C can significantly improve the throughput of associated multi-tasking Solaris driver software. SB-GPIB/TNT also implements the high-speed GPIB protocol (HS488), so data transfer speeds can exceed 3.6 MB/s.

Gpib-sprc-b is a high-performance GPIB interface board. The GPIB-SPRC-B interface board is assembled by National Instruments. The NI GPIB-SPRC-B is available for order with part number 776789-01. The GPIB-SPRC-B board belongs to the GPIB family of boards from National Instruments. The NI GPIB-SPRC-B board runs with the NI-488.2 driver software. The interface board can be used with LabVIEW and LabWindows/CVI for recommended software.

NI GPIB-SPRC-B is compatible with the Solaris operating system. The GPIB-SPRC-B interface board consists of the SB-GPIB/TNT board and NI-488.2 for Solaris. SB-GPIB/TNT can be inserted into a single wide main S-bus slot. Regular IEEE 488 cables can connect a circuit board to up to 14 devices. Multiple SB-GPIB/TNT boards can be inserted into a single computer to control multiple devices.

The interface board is designed to meet IEEE 488.2 standard compatibility. The GPIB-SPRC-B interface board provides the maximum GPIB data transfer rate. The GPIB-SPRC-B board can perform high-speed (HS-488) transfer rates in excess of 3.6 MB/s. The board supports an IEEE 488.1 data rate of over 1.4 MB/s. National Instruments GPIB-SPRC-B has software-controlled configuration options. NI GPIB-SPRC-B does not require any jumpers.

This IEEE 488 interface board was developed specifically to provide S-bus DVMA data transmission. The board is constructed with TNT4882C ASIC chip. Gpib-sprc-b can control the signal, which is used to render fast GPIB events. The NI GPIB-SPRC-B interface board is fully software compatible with all older versions of the SB-GPIB interface board at the time of manufacture.
