SCXI-1377  前置式接线端子 多路复用器或矩阵配置

【产品详情】

National Instruments SCXI-1377接线端子

NI SCXI-1377（部件号：778716-01）设计用于SCXI-1130开关模块。该前置安装接线端子可将SCXI-1130模块配置为：256x1、1线多路复用器、128x1、2线多路复用器、64x1、4线多路复用器，或独立配置为多路复用器或矩阵配置。该接线端子还可以实现在SCXI 1130开关模块的16x1构建块上构建的其他多路复用器尺寸。SCXI 1377具有弹簧端子和螺丝端子，用于将信号连接到开关。此外，还提供用于触发输入和触发输出信号的螺丝端子。NI 建议 使用 28 AWG 线 （带状 或 分立） 与 SCXI-1377 一起使用。

要将信号连接到NI SCXI-1377接线端子，用户需要接线端子、SCXI机箱、SCXI-1130开关模块、1/8英寸平头螺丝刀、飞利浦螺丝刀、剪线钳和电线绝缘剥线钳。首先，将绝缘层剥离至 7 毫米或更小，然后卸下顶盖螺钉。接下来，松开并取下顶盖。然后，用户可以松开应力消除组件上的两个应力消除螺钉，并取下顶部应力消除杆。然后，将信号线穿过应力消除开口。接下来，用户可以打开每个端子，并将电线的剥离部分放入端子中。确保电线牢固就位。将应力消除杆放回原处，然后拧紧应力消除组件上的两个螺钉以将电缆固定到位。最后，重新安装顶盖和顶盖螺丝。

相关部件号： 777687-77， 778716-01

SCXI-1377  前置式接线端子 多路复用器或矩阵配置

【英文介绍】

National Instruments SCXI-1377 wiring terminals

The NI SCXI-1377 (Part number: 778716-01) is designed for the SCXI-1130 switch module. The pre-mounting terminal allows the SCXI-1130 module to be configured as: 256x1, 1-wire multiplexer, 128x1, 2-wire multiplexer, 64x1, 4-wire multiplexer, or stand-alone multiplexer or matrix configuration. The terminal can also implement other multiplexer sizes built on the 16x1 building block of the SCXI 1130 switch module. The SCXI 1377 has spring terminals and screw terminals for connecting signals to the switch. In addition, screw terminals are provided for triggering input and triggering output signals. NI recommends 28 AWG wires (banded or discrete) for use with the SCXI-1377.

To connect the signal to the NI SCXI-1377 terminal, the user needs the terminal, SCXI chassis, SCXI-1130 switch module, 1/8-inch flat head screwdriver, Philips screwdriver, wire cutters, and wire insulation strippers. First, strip the insulation to 7 mm or less, then remove the top screw. Next, loosen and remove the top cover. The user can then loosen the two stress relief screws on the stress relief assembly and remove the top stress relief rod. Then, thread the signal wire through the stress relief opening. Next, the user can open each terminal and place the stripped portion of the wire into the terminal. Make sure the wires are securely in place. Put the stress relief rod back in place, then tighten the two screws on the stress relief assembly to hold the cable in place. Finally, reinstall the top cover and top screws.

Relevant part numbers: 777687-77, 778716-01
