SCXI-1350 多机箱适配器 连接到任何数据采集板

【产品详情】

National Instruments SCXI-1350 多机箱适配器

NI SCXI-1350（部件号：776575-50）需要SCXI机箱、SCXI模块、数据采集板、电缆、计算机和小平头螺丝刀才能使用适配器。该多机箱适配器允许用户将多机箱系统连接到数据采集板。SCXI 1350 可以使用以下模块：SCXI-1163、SCXI-1100、SCXI-1162、SCXI-1120、SCXI-1161、SCXI-1140、SCXI-1160 和 SCXI-1121。此外，SCXI-1181试验板模块和SCXI-1180馈通板可通过50引脚或100引脚带状电缆连接到任何数据采集板。

此多机箱适配器具有一个公背连接器、一个母模块连接器和一个公机箱扩展器连接器。用户可以利用带状电缆将背面连接器连接到数据采集板或以前的机箱。模块连接器插入 SCXI 模块的背面信号连接器，而另一根带状电缆将机箱连接器连接到以下机箱中的多机箱适配器。

NI SCXI-1350 的 连接 功能 包括 将 三 机 箱 系统 与 AT- MIO-16 数据 采集 板 连接。对于这种类型的链接，需要三根NBI电缆和三根National Instruments SCXI 1350多机箱适配器。用户应记住，如果他们使用 DIO 数据采集板为系统布线，则 DIO 板将控制所有机箱。但是，一些备用的 DIO 线路会混乱。当用户使用 MIO 数据采集板为系统布线时，多机箱适配器将 MIO 板的模拟通道 0 链接到初始机箱的模拟输出。MIO 板的模拟通道 1 链接到第二个机箱的模拟输出，依此类推。

SCXI-1350 多机箱适配器 连接到任何数据采集板

【英文介绍】

National Instruments SCXI-1350 more chassis adapters

The NI SCXI-1350 (Part number: 776575-50) requires the SCXI chassis, SCXI module, data acquisition board, cable, computer, and small flat head screwdriver to use the adapter. The multi-chassis adapter allows users to connect a multi-chassis system to a data acquisition board. The SCXI 1350 can use the following modules: SCXI-1163, SCXI-1100, SCXI-1162, SCXI-1120, SCXI-1161, SCXI-1140, SCXI-1160, and SCXI-1121. In addition, the SCXI-1181 test board module and SCXI-1180 Feedthrough board can be connected to any data acquisition board via a 50-pin or 100-pin ribbon cable.

This multi-case adapter has a male back connector, a female module connector, and a male case extender connector. Users can connect the rear connector to the data acquisition board or previous chassis using a ribbon cable. The module connector plugs into the signal connector on the back of the SCXI module, while another ribbon cable connects the case connector to the multi-case adapter in the following case.

The connection function of the NI SCXI-1350 includes the connection of the three-box system to the AT-MIO-16 data acquisition board. For this type of link, three NBI cables and three National Instruments SCXI 1350 multi-case adapters are required. Users should keep in mind that if they use the DIO data acquisition board to wire the system, the DIO board will control all enclosures. However, some alternate DIO lines can be confusing. When the user uses the MIO data acquisition board to wire the system, the multi-chassis adapter links the analog channel 0 of the MIO board to the analog output of the initial chassis. The analog channel 1 of the MIO board is linked to the analog output of the second chassis, and so on.
