National Instruments SCXI-1301 螺丝接线端子

SCXI 1301（部件号：777687-01）有20个螺丝端子，可以毫不费力地将信号连接到SCXI-1140模块。SCXI-1140模块的8个差分输入端子有8对螺丝端子，2个螺丝端子与模块的AGND相连，还有更多螺丝端子与HOLD信号以及功能机箱接地相连。NI SCXI-1301 可以 额外 安装在 SCXI-1181 和 SCXI-1181K 模 块 的 前部。该接线端子是屏蔽的，可确保简单快速的信号连接。

当用户将信号链接到模型时，他们可以按照SCXI-1301上的标签进行操作，该标签可在用户手册中找到。要将SCXI-1301接线端子连接到SCXI模块的前连接器，请先将接线端子连接到模块前连接器上的配对连接器。然后，用户可以拧紧SCXI-1301背面的顶部和底部翼形螺钉，以保持其牢固固定。

要使用 National Instruments SCXI 1301 螺丝接线端子，需要以下物品：剪线钳、电线绝缘剥线钳、长嘴钳、1/8 英寸。一字螺丝刀、1 号和 2 号飞利浦螺丝刀、SCXI 模块、SCXI 机箱和安装指南。用户应注意，未绝缘的电线穿过螺丝端子会增加附近信号短路的危险，从而导致电路故障。

SCXI-1301 螺丝接线端子 差分输入端子

【英文介绍】

National Instruments SCXI-1301 Screw terminal

The SCXI 1301 (Part number: 777687-01) has 20 screw terminals that allow for effortlessly connecting signals to the SCXI-1140 module. The eight differential input terminals of the SCXI-1140 module have eight pairs of screw terminals, two screw terminals are connected to the AGND of the module, and more screw terminals are connected to the HOLD signal and the ground of the functional chassis. The NI SCXI-1301 can be added to the front of the SCXI-1181 and SCXI-1181K modules. The terminal is shielded to ensure a simple and fast signal connection.

When users link the signal to the model, they can follow the label on the SCXI-1301, which can be found in the user manual. To connect the SCXI-1301 terminal to the front connector of the SCXI module, first connect the terminal to the pairing connector on the front connector of the module. The user can then tighten the top and bottom wing screws on the back of the SCXI-1301 to keep it firmly in place.

To use the National Instruments SCXI 1301 screw terminals, you will need the following: Wire cutters, wire insulation strippers, long nose pliers, 1/8 inch. Flat-head screwdriver, Philips screwdrivers 1 and 2, SCXI module, SCXI chassis, and installation guide. Users should note that an uninsulated wire passing through the screw terminal will increase the risk of a short circuit in the nearby signal, resulting in circuit failure.
