PCI-4060 数字万用表设备 能够精确地测量低值电阻

>>>>>型号:PCI-4060    数字万用表设备    能够精确地测量低值电阻

【功能描述】

PCI-4060是由National Instruments设计的一款先进的数字万用表设备。PCI 4060 DMM的部件号为777559-01。PCI-4060可以安装在基于PC的系统中。数字万用表可以读取与任何万用表相同的电压、电阻和电流测量值。此外，该设备还可以执行温度和频率测量。数字万用表还可用于二极管测试，可以测量交流和直流参数。PCI-4060是一款高性价比的器件。 PCI-4060万用表主要适用于OEM和教育实验室。

PCI-4060数字万用表可以在两种模式下工作：直流测量和交流测量。DC 模式的最大分辨率高达 5.5 位。直流模式的电压范围为+20 mV至+250V。交流电压范围为 20 Vrms 至 250 Vrms。NI PCI-4060 可以 测量 2 线 和 4 线 电阻。在 2 线模式下，范围可在 200 Ω 至 200 MΩ 之间选择。还提供自动量程选项。在 4 线电阻模式下，使用两对端子。4 线模式消除了引线电阻的影响。此功能使数字万用表能够精确地测量低值电阻。该模式的测量范围为 200 Ω 至 2 MΩ。

PCI-4060数字万用表也可用于测试二极管。PCI-4060在二极管测试模式下可测量高达2 V的电压。在这种模式下，PCI-4060激励二极管并测量压降。如果读数为 2.20 VDC，则表明被测二极管有缺陷或反向偏置。万用表的输入电阻为 1 Mohm，带宽为 20 Hz 至 25 kHz。它的推荐预热时间为 30 分钟。

NI 设备 尺寸 为 4.25 x 6.9 英寸。在物理维度上。它的推荐工作温度范围为 0 至 55 °C，存储温度范围为 -20 至 70 °C，非冷凝相对湿度范围为 10 至 90%。

PCI-4060数字万用表非常适合自动化生产测试、便携式音响场使用以及台式电子测试。它也可以与NI的交换模块，如PX系列模块，进行配合使用，进一步扩展其功能和应用范围。

此外，PCI-4060的易用性也是其一大优势。它无需编程即可创建、校准并部署视觉应用程序，使得用户可以更加便捷地进行各种测量和测试工作。

【英文介绍】

The PCI-4060 is an advanced digital multimeter device designed by National Instruments. The PCI 4060 DMM part number is 777559-01. PCI-4060 can be installed in PC-based systems. A digital multimeter can read the same voltage, resistance, and current measurements as any multimeter. In addition, the device can perform temperature and frequency measurements. Digital multimeters can also be used for diode testing and can measure AC and DC parameters. PCI-4060 is a cost-effective device. The PCI-4060 multimeter is mainly suitable for OEM and educational laboratories.

The PCI-4060 digital multimeter works in two modes: DC measurement and AC measurement. The maximum resolution in DC mode is up to 5.5 bits. The voltage range for DC mode is +20 mV to +250V. The AC voltage ranges from 20 Vrms to 250 Vrms. The NI PCI-4060 can measure 2-wire and 4-wire resistance. In 2-wire mode, the range can be selected between 200 Ω and 200 MΩ. Automatic range options are also available. In 4-wire resistance mode, use two pairs of terminals. The 4-wire mode eliminates the effect of lead resistance. This feature enables digital multimeters to accurately measure low value resistances. The measurement range of this mode is 200 Ω to 2 MΩ.

The PCI-4060 digital multimeter can also be used to test diodes. The PCI-4060 measures voltages up to 2 V in diode test mode. In this mode, the PCI-4060 excites the diode and measures the voltage drop. A reading of 2.20 VDC indicates that the diode under test is defective or reverse-biased. The multimeter has an input resistance of 1 Mohm and a bandwidth of 20 Hz to 25 kHz. It has a recommended warm-up time of 30 minutes.

The NI device measures 4.25 x 6.9 inches. In the physical dimension. It has a recommended operating temperature range of 0 to 55 °C, a storage temperature range of -20 to 70 °C and a non-condensing relative humidity range of 10 to 90%.

The PCI-4060 digital multimeter is ideal for automated production testing, portable sound field use, and benchtop electronic testing. It can also be used with NI switch modules, such as PX series modules, to further expand its function and application range.

In addition, the ease of use of PCI-4060 is also a big advantage. It can create, calibrate, and deploy visual applications without programming, making it easier for users to perform measurements and tests.
