PCI-1408 高精度单色 IMAQ 板卡 具有四通道的模拟视频输入功能

☆型号：PCI-1408    高精度单色 IMAQ 板卡    具有四通道的模拟视频输入功能

【产品详情】

特征：

单插槽PCI模块

图像采集卡

8 位数字化

National Instruments PCI-1408 设备是一款用于 PCI 插槽的高精度单色 IMAQ 板卡，支持 RS-170、CCIR、NTSC 和 PAL 视频标准。它还支持来自四个输入源中的任何一个的一些非标准相机。PCI-1408配置简单，便于安装电路板并开始图像采集。该设备实时采集帧并将其直接传输到系统内存。

PCI-1408具有8位闪存模数转换器（ADC），可将视频信号转换为数字格式。该器件因其低成本和高精度而成为工业和科学环境的理想选择。

PCI-1408具有四通道的模拟视频输入功能，支持合成或RGB彩色输入。这意味着它可以接收并处理多种视频信号源，适应不同的应用需求。此外，它同样支持标准的模拟视频信号（如RS-170, CCIR, NTSC, PAL, RGB）以及一些非标准视频信号，显示出其在信号兼容性方面的优势。

在硬件接口方面，PCI-1408对视频通道0提供了一个BNC接头，对于其他的定时信号则有一个25针的DSUB接头。这样的设计使得PCI-1408在连接各种视频设备和信号源时具有更大的灵活性和便利性。

1408 器件支持 4 个视频源和 4 个外部 I/O 线，可用作触发器或数字 I/O 线。如果需要更高级的触发或额外的I/O线路（数字或模拟），PCI-1408和NI-IMAQ软件可以与National Instruments数据采集（DAQ）产品线一起使用。

【英文介绍】

Features:

Single-slot PCI module

Image capture card

8-bit digitizing

The National Instruments PCI-1408 device is a high-precision monochrome IMAQ board for PCI slots that supports RS-170, CCIR, NTSC, and PAL video standards. It also supports some non-standard cameras from any of the four input sources. The PCI-1408 is simple to configure, making it easy to mount the circuit board and start image acquisition. The device captures frames in real time and transfers them directly to system memory.

The PCI-1408 features an 8-bit flash analog-to-digital converter (ADC) that converts video signals to a digital format. The device is ideal for industrial and scientific environments due to its low cost and high precision.

The PCI-1408 has a four-channel analog video input capability and supports synthetic or RGB color inputs. This means that it can receive and process multiple video sources, adapting to different application requirements. In addition, it also supports standard analog video signals (such as RS-170, CCIR, NTSC, PAL, RGB) as well as some non-standard video signals, showing its advantage in signal compatibility.

In terms of hardware interface, the PCI-1408 provides a BNC connector for video channel 0 and a 25-pin DSUB connector for other timing signals. This design gives the PCI-1408 greater flexibility and convenience in connecting various video devices and signal sources.

The 1408 device supports four video sources and four external I/O wires, which can be used as a trigger or digital I/O wire. If more advanced triggering or additional I/O wiring (digital or analog) is required, the PCI-1408 and NI-IMAQ software can be used with the National Instruments Data Acquisition (DAQ) product line.
