PCI-6031E 高性能的数据采集卡 保证了设备的轻便性和便携性

☆型号：PCI-6031E   高性能的数据采集卡    保证了设备的轻便性和便携性

【产品详情】

PCI-6031E是一款高性能的数据采集卡，广泛应用于各种需要精确数据采集的场合。以下是对PCI-6031E的详细介绍：

PCI-6031E具有双电源冗余输入设计，这增强了其供电的稳定性和可靠性。其电源电压范围为DC(9-36)V，典型值为DC24V，功耗小于4W，且具备DC1500V的电压隔离以及反接保护功能，确保了设备在复杂环境下的安全稳定运行。

在机械特性方面，PCI-6031E的外形尺寸为132mm×105mm×52mm，外壳采用IP30防护等级，并配有波浪纹铝制加强机壳，这为其提供了良好的物理保护。其安装方式采用35mmDIN导轨安装，使得安装过程更为简便。同时，该设备的净重为800g，保证了设备的轻便性和便携性。

在性能上，PCI-6031E具有光纤链路故障和电源故障告警输出功能，触点容量为DC48V/1A，确保了设备的实时故障检测与报警。这使得用户能够及时发现并处理设备故障，避免数据损失或设备损坏。

特征：

（64） 单端/32 差分模拟输入

（2） 16 位模拟输出

（8） 数字 I/O 线

（2） 24 位计数器

模拟触发

National Instruments PCI-6031E是一款功能齐全的多路复用数据采集设备。当与NI信号调理配合使用时，该设备非常适合从连续高速数据记录到控制应用，再到高压信号或传感器测量等应用。

PCI-6031E包括以下特性和技术：

- 板载自校准

- 分辨率改进技术

- NI DAQ-STC

- 镍螨

- PFI线路

- 温度漂移保护电路

- NI PGIA

- RSE MODE

- RTSI 或 PXI 触发 总

线 - 板载温度传感器

- 模拟和数字触发

【英文介绍】

PCI-6031E is a high performance data acquisition card, widely used in a variety of applications requiring accurate data acquisition. The following is a detailed introduction to PCI-6031E:

The PCI-6031E has a dual power supply redundant input design, which enhances the stability and reliability of its power supply. Its power supply voltage range is DC(9-36)V, the typical value is DC24V, the power consumption is less than 4W, and has DC1500V voltage isolation and reverse protection function, to ensure the safe and stable operation of the equipment in complex environments.

In terms of mechanical properties, the PCI-6031E has an external dimension of 132mm×105mm×52mm, an IP30 protection grade in the housing, and a wavy aluminum reinforcing case, which provides good physical protection. The installation method is 35mmDIN rail mounting, which makes the installation process easier. At the same time, the net weight of the device is 800g, which ensures the lightness and portability of the device.

In terms of performance, PCI-6031E has the alarm output function of fiber link fault and power failure, and the contact capacity is DC48V/1A, which ensures the real-time fault detection and alarm of the device. This enables users to detect and deal with equipment failures in a timely manner, avoiding data loss or equipment damage.

Features:

(64) Single-ended /32 differential analog input

(2) 16-bit analog output

(8) Digital I/O cables

(2) 24-bit counter

Simulated trigger

The National Instruments PCI-6031E is a fully functional multiplex data acquisition device. When used in conjunction with NI signal conditioning, the device is ideal for applications ranging from continuous high-speed data recording to control applications, to high voltage signal or sensor measurement.

PCI-6031E includes the following features and technologies:

- Onboard self-calibration

- Resolution improvement technology

- NI DAQ-STC

- Nickel mites.

- PFI line

- Temperature drift protection circuit

- NI PGIA

- RSE MODE

- RTSI or PXI trigger total

Wire-on-board temperature sensor

- Analog and digital triggers
