PCI-6071E 工控机配件 支持与运动控制和任务视觉的集成

>>>>>型号:PCI-6071E     工控机配件    支持与运动控制和任务视觉的集成

【功能描述】

零件编号：PCI-6071E系列

厂家：美国国家仪器

子类别：工控机配件

PCI-6070E是National Instruments的多功能DAQ。PCI-6070E的部件号为777305-01。PCI-6070E是高速、高精度的多路复用DAQ设备之一。该器件的突出特点是灵活性、抗噪性和抗抖动性。PCI-6070E具有低功耗和自校准功能。自校准通过软件控制。该型号还具有温度漂移保护功能。NI PCI-6070E 设备 支持 各种 操作系统 和 应用 软件 选择， 如 LabVIEW、 LabWindows/ CVI 或 Measurement Studio。PCI-607E提供70多种信号调理选择。该器件支持RTSI触发总线，使PCI-6070E能够同步多个器件。

PCI-6070E多功能DAQ有32个模拟输入通道。这些通道可以编程为 16 个差分输入。该模型的每个通道都是独立的。输入通道的电压范围为 10 伏。该器件的输入通道支持双极性。这些通道可选择为单极性和双极性。在双极性模式下，电压范围为-5 V至+5 V。输入通道的ADC分辨率为12位。该设备的最大采样时间为 1.25 MS/秒。DAQ设备有2个模拟输出通道，分辨率为12位，采样率为1 MS/s。它具有 8 个数字 I/O 通道（兼容 5 V/TTL）和 2 个计数器/定时器 I/O 线（分辨率为 24 位，频率为 20 MHz）。NI PCI-6070E 包括 一个 FIFO 缓冲 器。FIFO 缓冲区的内存为 2,048 个样本。该器件配备 68 针公头 0.050 D 型 I/O 连接器。

PCI-6070E是各种应用的理想选择。该设备可以不间断地记录快速数据。该器件还用于控制应用。NI PCI-6070E 兼容 高压 信号 和 传感器 测量。该模型支持与运动控制和任务视觉的集成。此属性使其适用于设计控制系统。

【英文介绍】

Part number: PCI-6071E series

Manufacturer: National Instruments

Subcategory: Industrial computer accessories

The PCI-6070E is a versatile DAQ from National Instruments. The PCI-6070E part number is 777305-01. PCI-6070E is one of the high speed and high precision multiplexing DAQ devices. The outstanding features of the device are flexibility, anti-noise and anti-jitter. The PCI-6070E features low power consumption and self-calibration. Self-calibration is controlled by software. This model also features temperature drift protection. NI PCI-6070E devices support a variety of operating systems and application software options, such as LabVIEW, LabWindows/ CVI, or Measurement Studio. The PCI-607E offers more than 70 signal conditioning options. The device supports the RTSI trigger bus, enabling the PCI-6070E to synchronize multiple devices.

The PCI-6070E multi-function DAQ has 32 analog input channels. These channels can be programmed for 16 differential inputs. Each channel in the model is independent. The voltage range of the input channel is 10 volts. The input channel of the device supports bipolar. These channels can be selected as unipolar or bipolar. In bipolar mode, the voltage range is -5 V to +5 V. The ADC resolution of the input channel is 12 bits. The device has a maximum sampling time of 1.25 MS/ s. The DAQ device has 2 analog output channels with a resolution of 12 bits and a sampling rate of 1 MS/s. It features eight digital I/O channels (compatible with 5 V/TTL) and two counter/timer I/O lines (24 bit resolution and 20 MHz frequency). The NI PCI-6070E includes a FIFO buffer. The memory of the FIFO buffer is 2,048 samples. The device is equipped with a 68-pin male type 0.050D I/O connector.

The PCI-6070E is ideal for a variety of applications. The device can record fast data without interruption. The device is also used in control applications. The NI PCI-6070E is compatible with high voltage signal and sensor measurement. The model supports integration with motion control and task vision. This property makes it suitable for design control systems.
