SCX1-1193 复用器开关模块 可以同时处理32个通道的RF信号

☆型号：SCX1-1193 复用器开关模块 可以同时处理32个通道的RF信号

【产品详情】

SCX1-1193是NI (National Instruments,美国国家仪器公司)生产的一款高密度、 32通道RF多路复用器开关模块。 这款模块可以通过编程配置为

未端接多路复用器、外部端接多路复用器或尺寸灵活的稀疏矩阵，适用于不同的应用场景。

SCXI-1193的主要特性和功能包括:

1.高密度设计:可以同时处理32个通道的RF信号。

2.可编程配置:可以通过编程来配置为不同的模式(未端接多路复用器、外部端接多路复用器或稀疏矩阵)。

3.高速响应:适用于需要快速响应的应用场景。

4.可靠性:适用于各种需要高可靠性控制的应用场景。

5.易于集成:可以方便地与NI的其他设备集成使用，如PXIl任意波形发生器和示波器等。

这镍SCX1-1193(零件号:776572-93)是高密度的，32通道RF多路复用器开关模块，可安排为未端接多路复用器、外部端接多路复用器或维度通用的稀疏矩阵。每种配置都能承受从DC到500MHz以上的信号频率。该模块有一个插槽 ,并利用高密度推进式MCX连接器进行离散但易于管理的布线。该模块不能将信号导向高压模拟总线。这SCX1-1193是为 了与高频设备集成而创建的，包括PXI-5404频率发生器和PXI-5112高速数字化仪。SCXI1193可实现以下拓扑结构;四路8x1多路复用器、四路4x 1端接多路复用器、双路16x1多路复 用器、双路8x1端接多 路复用器、32x1多路复用器、16x1端接多 路复用器和独立模块。这射频多路复用器开关模块可用于多种不同的电缆。

【英文介绍】

The SCX1-1193 is a high-density, 32-channel RF multiplexer switch module manufactured by National Instruments (NI). This module can be programmed to

Unterminated multiplexers, externally terminated multiplexers or dimensional flexible sparse matrices for different application scenarios.

Key features and functions of the SCXI-1193 include:

1. High density design: RF signals of 32 channels can be processed simultaneously.

2. Programmable configuration: Can be programmed to be configured for different modes (unterminated multiplexer, externally terminated multiplexer or sparse matrix).

3. High-speed response: Applicable to application scenarios that require fast response.

4. Reliability: Applicable to various application scenarios that require high reliability control.

5. Easy integration: It can be easily integrated with other NI devices, such as PXIl arbitrary waveform generator and oscilloscope.

This nickel SCX1-1193(Part number :776572-93) is a high-density, 32-channel RF multiplexer switch module that can be arranged as an unterminated multiplexer, an externally terminated multiplexer, or a dimensionally generic sparse matrix. Each configuration can withstand signal frequencies from DC to more than 500MHz. The module has a slot and utilizes high-density pusher MCX connectors for discrete but manageable wiring. The module cannot direct the signal to the high voltage analog bus. The SCX1-1193 was created for integration with high-frequency devices, including the PXI-5404 frequency generator and the PXI-5112 high-speed digitizer. SCXI1193 can implement the following topologies; Four-way 8x1 multiplexer, four-way 4x 1-end multiplexer, two-way 16x1 multiplexer, two-way 8x1 end multiplexer, 32x1 multiplexer, 16x1 end multiplexer and independent module. This RF multiplexer switch module can be used for a variety of different cables.
