☆型号：PCI-7813R 数字可重构 I/O 设备 使用实时系统集成
【产品详情】
National Instruments PCI-7813R 数字可重构 I/O 设备
PCI-7813R （部件号： 779370-01） 是National Instruments的R系列数字可重配置I/O设备。此设备使用实时系统集成 （RTSI） 总线。 R 系列 PCI 小工具通过小工具之间关联的 RTSI 链路访问 RTSI 传输。另一方面， R 系列 PXI 小工具 通过 PXI 背 板 上 执行 的 PXI 触发 线 到达 RTSI 总 线。CompactPCI判定授予商家创建子总线的权力，这些子总线与CompactPCI总线上的基本PCI接口一起存在。在具有各种子总线的 CompactPCI 小工具之间，以及具有子总线的 CompactPCI 小工具和 PXI 之间，都无法确保完美的活动。CompactPCI的标准用法不包括这些子总线。R 系列小工具适用于任何标准 CompactPCI 底盘系统，紧紧抓住 PICMG CompactPCI 2.0 R3.0 中心细节。
该型号配有NSC68-262650链路，可将NI PCI-7813R RMIO连接器上的信号直接连接到5B和SSR背板。该 链路 的 一侧 有 一个 68 棒 公 VHDCI 连接器， 可 插入 NI PCI-7813R RMIO 连接器。此链接的另一端除了一个 26 棒母连接器外，还提供两个 50 棒母连接器。其中一个 26 棒 连接器 包含 所有 NI PCI-7813R 简单 信息 信号。用户可以将此连接器直接连接到 5B 背板，以实现简单的输入信号成型。该器件还配备了 4 个 68 针母头高密度 VHDCI I/O 连接器。NI PCI-7813R AI<0..n>与5B背板相关，并在连续请求中指向<0..n>。用户可以在利用 5B 信号成型时安排 AI 通道以利用 NRSE 输入模式。PCI-7813R具有160条数字I/O线，嵌入式块RAM为1.728 kbits。
☆型号：PCI-7813R 数字可重构 I/O 设备 使用实时系统集成
【英文介绍】
National Instruments PCI-7813R digital reconfigurable I/O device
The PCI-7813R (Part number: 779370-01) is a digital reconfigurable I/O device from National Instruments' R series. This device uses the Real-time System Integration (RTSI) bus. The R Series PCI gadgets access RTSI transport through the RTSI links associated between the gadgets. On the other hand, the R Series PXI gadget reaches the RTSI master wire through the PXI trigger wire executed on the PXI backboard. The CompactPCI decision grants the merchant the right to create subbuses that exist along with the base PCI interface on the CompactPCI bus. Perfect activity cannot be ensured between CompactPCI widgets with each seed bus, or between CompactPCI widgets with subbuses and PXI. The standard usage of CompactPCI does not include these subbuses. The R Series gadget works with any standard CompactPCI chassis system, grasping the PICMG CompactPCI 2.0 R3.0 central details.
This model is equipped with an NSC68-262650 link that connects signals from the NI PCI-7813R RMIO connector directly to the 5B and SSR backplane. On one side of the link is a 68-bar male VHDCI connector that plugs into the NI PCI-7813R RMIO connector. The other end of this link provides two 50-bar female connectors in addition to a 26-bar female connector. One 26-bar connector contains all NI PCI-7813R simple message signals. Users can connect this connector directly to the 5B backplane for simple input signal molding. The device is also equipped with four 68-pin female high-density VHDCI I/O connectors. NI PCI-7813R AI<0.. n> is associated with the 5B backplane and points to <0 in successive requests... n>. Users can arrange AI channels to take advantage of NRSE input modes while utilizing 5B signal molding. The PCI-7813R has 160 digital I/O lines and 1.728 kbits of embedded block RAM.
