VMVME-7698-345 350-017698-345 B 单槽插座370处理器 支持Windows NT和Windows 2000的操作系统

>>>>>型号:VMVME-7698-345 350-017698-345 B 单槽插座370处理器 支持Windows NT和Windows 2000的操作系统

【功能描述】

 该VMIVME- 7698-146单元配备了一个赛扬单槽插座370处理器。它设计了一个能够支持Windows NT和Windows 2000的操作系统，然后是Linux、VxWorks、 QNX和Solaris.VMIVME-7698-146模块配备了一系列嵌入式应用的特殊功能。有高达512兆字节的IDE CompactFlash(可选)。有三个可编程的16位定时器，32千 字节的电池支持的SRAM。

特点:

赛扬插座370处理器

64位英特尔AGP SVGA控制器，带2兆字节SGRAM

板载快速以太网控制器，支持10BaseT和100BaseTX接口

带有VMEbus P2 /O的板载Ultra DMA33硬盘和Foppy驱动器控制器

两个高性能16550兼容串行端口

前面板上的PS/2风格键盘和鼠标端口

VME64连接器

基于Abaco Systems / VMIC VMIVME 7698单槽赛扬插座370处理器的VME / VME64单板计算机配有带MMX的英特尔赛扬处理器。赛扬处理器

具有32位寻址和64位数据总线。板载DRAM是VMEbus的双端口。系统和视频BIOS被提供在可重新编程的闪存中。VMIVME-7698为用户提供了三

个16位定时器(除了系统定时器之外),与82C54兼容。这些定时器映射到/O空间,并且完全是软件可编程的。

【英文介绍】

The VMIVME-7698-146 unit is equipped with a Celeron single-slot socket 370 processor. It designed an operating system capable of supporting Windows NT and Windows 2000, followed by Linux, VxWorks, QNX and Solaris.VMIVME-7698-146 modules equipped with special features for a range of embedded applications. Up to 512 megabytes of IDE CompactFlash is available (optional). There are three programmable 16-bit timers, 32 kilobyte battery support SRAM.

Features:

Celeron Socket 370 processor

64-bit Intel AGP SVGA controller with 2 megabytes of SGRAM

Onboard fast Ethernet controller with 10BaseT and 100BaseTX interfaces

Onboard Ultra DMA33 hard drive and Foppy drive controller with VMEbus P2 /O

Two high-performance 16550 compatible serial ports

PS/2 style keyboard and mouse ports on the front panel

VME64 connector

The VME/VME64 single-board computer based on the Abaco Systems/VMIC VMIVME 7698 single-slot Celeron Socket 370 processor is equipped with an Intel Celeron processor with MMX. Celeron processor

It has 32-bit addressing and 64-bit data bus. The onboard DRAM is the dual port of the VMEbus. The system and video BIOS are provided in reprogrammable flash memory. VMIVME-7698 provides users with three

16 bit timers (in addition to system timers), compatible with 82C54. These timers map to the /O space and are completely software programmable.
