METSO  IOP345 允许任何操作员或用户通过提供的监视器，触摸输入接口和通信接口监视或控制连接的机器或过程。为了监控系统，提供的 12 英寸彩色薄膜晶体管 （TFT） 显示屏能够通过定制设计的模拟提供过程的可视化。

此外，彩色显示屏支持实现彩色编码动画和状态显示，以提高信息水平。控制命令通过触摸感应屏幕输入，允许操作员通过触摸相应的运行时图标或对象直接输入命令。

与控制器的通信是使用单个RS232 / RS485组合端口在点对点或多点串行拓扑中完成的，而网络和多节点通信则通过支持10/100 Mbps传输速率的以太网通信接口完成。

该操作面板支持历史数据记录、View 和 Visual Basic 与 Proficy Machine Edition 5.0 或更高版本一起使用时。

设计为现代接口机器QuickPanel组的一部分。终端使客户能够通过RS-232/RS-485通信端口和关联的HMI-CAB-C110通信链路使用Proficy View（机器版）编程软件与机器进行接口。用户可以使用触摸屏输入数据和信息。

METSO  IOP345 触摸输入接口  通信接口监视

The METSO IOP345 Warehouse Spot module allows any operator or user to monitor or control connected machines or processes through the provided monitor, touch input interface and communication interface. To monitor the system, the supplied 12-inch color thin-film transistor (TFT) display provides visualization of the process through custom-designed simulations. In addition, the color display supports color-coded animation and status display to improve the level of information. Control commands are entered via a touch-sensitive screen, allowing the operator to enter commands directly by touching the corresponding runtime icon or object. Communication with the controller is done in a point-to-point or multipoint serial topology using a single RS232 / RS485 combination port, while network and multi-node communication is done via an Ethernet communication interface that supports 10/100 Mbps transmission rates. The action panel supports historical data logging, View, and Visual Basic when used with Proficy Machine Edition 5.0 or later.

Designed as part of the QuickPanel group for modern interface machines. The terminal enables the customer to interface with the machine using Proficy View (Machine Edition) programming software via the RS-232/RS-485 communication port and the associated HMI-CAB-C110 communication link. Users can enter data and information using the touch screen.
