S74802-NANANA 数字伺服驱动器 具有扩展功能的

☆型号：S74802-NANANA 数字伺服驱动器 具有扩展功能的

【产品详情】

特性：

安全性： 该驱动器经过CE、UL和TÜV安全测试，确保在各种应用中的安全使用。

电源： 直接从接地110至480 VAC线路操作，适用于1或3相，50至60 Hz的电源。

输出电流： 最大连续输出电流从1.5到72安培均方根/相位的型号可选。

安全功能： 板载安全扭矩关闭(STO)功能，并提供了安全扩展卡，可提供SIL2或SIL3安全功能。

通信接口： 支持EtherCAT®和CANopen总线通信，同时还有传统总线如PROFINET、DeviceNet、PROFIBUS DP、SERCOS II和RS232。

反馈系统： 单电缆反馈SFD3和Hiperface DSL，提供了优化的解析器接口。

存储功能： 配备MMC存储卡插槽，可用于备份和复制参数及固件。

自动调谐： 该驱动器具有自动调谐功能。

连接性： 提供了多种连接方式，如接头压制，并支持所有标准控制器和反馈系统。

EMC滤波器和集成电源、制动电阻： 板载EMC滤波器和集成电源和制动电阻使设备更小，节省了开关柜空间。

好处：

高效率： 高速的电流、速度和位置控制提高了机器的循环率。

高可用性： 安全功能SIL2 / SIL3提高了机器的可用性。

灵活性： 内置IEC 61131宏编程语言使运动控制更加灵活。

减少库存需求： 多接口和多反馈功能提供了与所有标准控制器和反馈系统的兼容性，减少了库存多种驱动类型的需要。

快速设置与维护： 用于参数和固件更新的存储卡、自动调谐功能和所有连接的连接器有助于更快的设置和维护。

这些特性与好处表明该电机驱动器在工业自动化领域中具有很高的应用价值，特别是在需要高精度、高速度、高安全性和易用性的场景中。

☆型号：S74802-NANANA 数字伺服驱动器 具有扩展功能的

【英文介绍】

Features:

Safety: The drive is CE, UL and TUV safety tested to ensure safe use in a variety of applications.

Power Supply: Operate directly from grounded 110 to 480 VAC lines for 1 or 3 phase, 50 to 60 Hz power supplies.

Output current: Models with maximum continuous output current from 1.5 to 72 amps RMS/phase are optional.

Safety features: On-board Safety Torque Off (STO) function, and a safety expansion card is available to provide SIL2 or SIL3 safety features.

Communication interface: Supports EtherCAT® and CANopen bus communication, as well as traditional buses such as PROFINET, DeviceNet, PROFIBUS DP, SERCOS II and RS232.

Feedback system: Single cable feedback SFD3 and Hiperface DSL provide an optimized parser interface.

Storage function: Equipped with MMC memory card slot for backing up and copying parameters and firmware.

Automatic tuning: The driver has an automatic tuning function.

Connectivity: A variety of connections are available, such as joint pressing, and all standard controllers and feedback systems are supported.

EMC Filter and integrated power supply, brake resistance: Onboard EMC filter and integrated power supply and brake resistance make equipment smaller and save switch cabinet space.

Benefits:

High efficiency: High current, speed and position control increase the cycle rate of the machine.

High Availability: The security feature SIL2 / SIL3 improves the availability of the machine.

Flexibility: The built-in IEC 61131 macro programming language makes motion control more flexible.

Reduced inventory requirements: Multi-interface and multi-feedback capabilities provide compatibility with all standard controllers and feedback systems, reducing the need for multiple drive types for inventory.

Quick setup and maintenance: Memory card for parameter and firmware updates, auto-tuning function and connectors for all connections facilitate faster setup and maintenance.

These characteristics and benefits show that the motor driver has a high application value in the field of industrial automation, especially in the need for high precision, high speed, high safety and ease of use.
