HONEYWELL CC-TAIX01 模拟输入在PLC存储器中的位置使用

HONEYWELL CC-TAIX01由于存储器地址不依赖于物理I/O寄存器，因此可以由用户自行决定。定义新标签时，首先选择M(用于记忆存储)。如果标签必须是单个比特，则结构可以是M4.1，例如第5个字节的第二个比特。

如果标签必须是一个完整的字节，标签将是MB4，下一个将是MB5。随着整数大小的增加，例如一个字，MW4可能是第一个标签，但是MW6必须是下一个，因为16位字消耗两个连续的字节。双字的大小是一个字的两倍，所以MD4后面必须跟MD8。

HONEYWELL CC-TAIX01同样，10个输出引脚的前8个引脚寻址为Q0.0至Q0.7，其余2个引脚寻址为Q1.0至Q1.1。

该PLC有两个模拟输入端子。由于它们不是单比特值，因此必须作为16比特字来引用。因为存储器被分成字节，所以存储一个字需要两个连续的字节。这是通过使用具有输入结构(I)的地址，将其表示为单词(W ),并确保只使用每隔一…字节地址。

HONEYWELL CC-TAIX01  模拟输入

Brand :Honeywell

Model: CC-TAIX01

Product description

HONEYWELL CC-TAIX01 simulates the use of input positions in PLC memory

HONEYWELL CC-TAIX01 Because the memory address does not depend on the physical I/O register, it can be decided by the user. When defining a new label, first select M(for memory storage). If the label must be a single bit, the structure can be M4.1, such as the second bit of the fifth byte.

If the label had to be a full byte, the label would be MB4 and the next one would be MB5. As the integer size increases, such as a word, MW4 may be the first label, but MW6 must be the next, because the 16-bit word consumes two consecutive bytes. A double word is twice the size of a single word, so MD4 must be followed by MD8.

HONEYWELL CC-TAIX01 Similarly, the first eight of the 10 output pins are addressed Q0.0 to Q0.7, and the remaining two pins are addressed Q1.0 to Q1.1.

The PLC has two analog input terminals. Since they are not single-bit values, they must be referenced as 16-bit words. Because memory is divided into bytes, it takes two consecutive bytes to store a word. This is done by using an address with an input structure (I), representing it as a word (W), and ensuring that only every other... Byte address.
